SEAT ASSY для Yamaha VENTURE 500 XL - 2000 года выпуска
-
№АртикулНазвание
-
18CY-24730-20-00 DOUBLE SEAT ASSEMBLYDOUBLE SEAT ASSEMBLY
-
28CY-2470F-20-00 ...COVER, SEAT...COVER, SEAT
-
395707-08300-00 NUT, FLANGENUT, FLANGE
-
490201-086A3-00 WASHER, PLATEWASHER, PLATE
-
58CW-24790-10-00 SEAT BACK ASSEMBLYSEAT BACK ASSEMBLY
-
68CW-2474H-01-00 BRACKET, ASSIST GRIP 1BRACKET, ASSIST GRIP 1
-
78CW-2474J-01-00 BRACKET, ASSIST GRIP 2BRACKET, ASSIST GRIP 2
-
88CW-24797-00-00 BRACKET, SEAT BACKBRACKET, SEAT BACK
-
98CW-2479L-00-00 BRACKET, SEATBRACKET, SEAT
-
108CW-2479H-00-00 BODY, SEAT LOCKBODY, SEAT LOCK
-
1190201-083A8-00 WASHER, PLATEWASHER, PLATE
-
128CW-24737-00-00 DAMPER, SEATDAMPER, SEAT
-
138CW-2474A-00-00 ASSIST, GRIPASSIST, GRIP
-
148CW-2474B-00-00 ASSIST GRIP WARMER ASSY 1ASSIST GRIP WARMER ASSY 1
-
158CW-2474C-00-00 ASSIST GRIP WARMER ASSY 2ASSIST GRIP WARMER ASSY 2
-
1690267-47187-00 RIVET, BLINDRIVET, BLIND
-
1790560-08251-00 SPACERSPACER
-
1895807-08016-00 BOLT, FLANGEBOLT, FLANGE
-
1995807-06040-00 BOLT, FLANGEBOLT, FLANGE
-
2095307-06800-00 NUTNUT
-
2192907-06200-00 WASHERWASHER
-
2297707-50016-00 SCREW, TAPPINGSCREW, TAPPING
-
2395807-08014-00 BOLT, FLANGEBOLT, FLANGE
-
2490464-13077-00 CLAMPCLAMP
-
258CR-24734-00-00 BAND, SEATBAND, SEAT
-
2690154-06040-00 SCREW, BINDINGSCREW, BINDING
