TUNNEL ASSEMBLY W/ LOWER NOSEPAN для Yamaha VENTURE 500 XL - 2000 года выпуска
-
№АртикулНазвание
-
18DJ-21940-08-00 FRONT FRAME COMPFRONT FRAME COMP
-
28CR-2191A-00-00 ...BULKHEAD...BULKHEAD
-
390267-48176-00 ...RIVET, BLIND...RIVET, BLIND
-
490267-48177-00 ...RIVET, BLIND...RIVET, BLIND
-
58CR-21950-06-00 REAR FRAME COMPREAR FRAME COMP
-
68CR-21960-08-00 FOOTREST COMP. 1FOOTREST COMP. 1
-
78CR-21970-08-00 FOOTREST COMP. 2FOOTREST COMP. 2
-
88DJ-W2195-01-00 FRAME CONNECTION KITFRAME CONNECTION KIT
-
98CR-21943-01-00 ...BRACKET, MAIN TRACK 1...BRACKET, MAIN TRACK 1
-
108CR-21953-00-00 ...BRACKET, MAIN TRACK 2...BRACKET, MAIN TRACK 2
-
118CR-2196F-00-00 ...BRACKET 3...BRACKET 3
-
128CR-21920-00-00 ...HOUSING, REINF SUB-ASSEMBLY (L.H)...HOUSING, REINF SUB-ASSEMBLY (L.H)
-
138CR-21939-00-00 ...BRACKET, CHAIN HOUSING...BRACKET, CHAIN HOUSING
-
148CR-21977-00-00 ...CLAMP, FUEL PIPE...CLAMP, FUEL PIPE
-
158CR-21917-00-00 ...PANEL, SUB FRAME 6...PANEL, SUB FRAME 6
-
168CR-21918-00-00 ...PANEL, SUB-FRAME 7...PANEL, SUB-FRAME 7
-
1790267-48176-00 ...RIVET, BLIND...RIVET, BLIND
-
188CR-2194J-00-00 ...STAY, MUFFLER...STAY, MUFFLER
-
1990267-47186-00 ...RIVET, BLIND (UR UN)...RIVET, BLIND (UR UN)
-
1990267-47197-00 ...RIVET, BLIND (UR UN)...RIVET, BLIND (UR UN)
-
2090461-05003-00 ...CLAMP...CLAMP
-
2190461-06142-00 ...CLAMP...CLAMP
-
2290462-05059-00 ...CLAMP...CLAMP
-
2390465-08368-00 ...CLAMP...CLAMP
-
248DF-21941-00-00 PIPE, PIVOT 1PIPE, PIVOT 1
-
258DF-21951-00-00 PIPE, PIVOT 2PIPE, PIVOT 2
-
2690269-07080-00 RIVETRIVET
-
278CR-2198F-00-00 COVER 1COVER 1
-
288CR-2195E-00-00 PLATE, STRG BRACKET 1PLATE, STRG BRACKET 1
-
2990267-48165-00 RIVET, BLINDRIVET, BLIND
-
308CR-21912-01-00 PANEL, SUB FRAME 1PANEL, SUB FRAME 1
-
318CR-23788-11-00 PLATE, BACK UPPLATE, BACK UP
-
328CR-77128-00-00 STAY 4STAY 4
-
338CR-2196A-02-00 FRAME UNDER 1FRAME UNDER 1
-
348DJ-2196E-01-00 FRAME, UNDER 2FRAME, UNDER 2
-
358CR-21972-00-00 BRACKET, GUARD FITTINGBRACKET, GUARD FITTING
-
3690267-48141-00 RIVET, BLINDRIVET, BLIND
-
3790201-05033-00 WASHER, PLATEWASHER, PLATE
-
3890267-47187-00 RIVET, BLINDRIVET, BLIND
-
398CR-77512-00-00 BUMPER, FRONT 2BUMPER, FRONT 2
-
4095807-08020-00 BOLT, FLANGEBOLT, FLANGE
-
418CR-21949-10-00 BRACKET, FRONTBRACKET, FRONT
-
428CR-21959-10-00 BRACKET, FRONT BUMPERBRACKET, FRONT BUMPER
-
4395607-08200-00 NUT, SELF-LOCKINGNUT, SELF-LOCKING
-
448CR-2196M-00-00 BRACKET, 5BRACKET, 5
-
4595807-08040-00 BOLT, FLANGEBOLT, FLANGE
-
4690387-0810F-00 COLLARCOLLAR
-
4795707-08500-00 NUT, FLANGENUT, FLANGE
-
4890465-08146-00 CLAMPCLAMP
-
498CR-2198J-00-00 COVER 3COVER 3
-
508DX-21991-01-00 REINF., PANEL FRAME 1REINF., PANEL FRAME 1
-
518DX-21992-01-00 REINF., PANEL FRAME 2REINF., PANEL FRAME 2
-
5290267-47186-00 RIVET, BLINDRIVET, BLIND
-
538CR-21923-02-00 REINEFORCEMENT, FRAME REAR 1REINEFORCEMENT, FRAME REAR 1
-
5490267-47186-00 RIVET, BLINDRIVET, BLIND
-
5595027-08016-00 BOLT, FLANGEBOLT, FLANGE
-
5695707-08500-00 NUT, FLANGENUT, FLANGE
-
578CR-21973-00-00 HOOKHOOK
-
5890267-48169-00 RIVET, BLINDRIVET, BLIND
-
5981K-2471F-00-00 BUTTONBUTTON
-
6090267-40069-00 RIVET, BLINDRIVET, BLIND
-
618CR-21921-01-00 REINEFORCEMENT, FRAME REAR 1REINEFORCEMENT, FRAME REAR 1
-
6290105-10617-00 BOLT, WASHER BASEDBOLT, WASHER BASED
-
6395827-10065-00 BOLT, FLANGEBOLT, FLANGE
-
6495707-10500-00 NUT, FLANGENUT, FLANGE
-
6592907-10200-00 WASHER, PLAINWASHER, PLAIN
-
668CR-2198J-00-00 COVER 3COVER 3
-
6790338-10004-00 PLUGPLUG
-
6890267-48177-00 RIVET, BLINDRIVET, BLIND
-
6990338-44093-00 PLUGPLUG
-
7090338-30256-00 PLUGPLUG
-
718DF-21998-00-00 SPACERSPACER
-
728DJ-2197C-00-00 PROTECTOR, FRAME 3PROTECTOR, FRAME 3
-
7390267-48141-00 RIVET, BLINDRIVET, BLIND
-
748DJ-77261-00-00 LINING, SHROUD 1LINING, SHROUD 1
-
758DJ-77262-00-00 LINING, SHROUD 2LINING, SHROUD 2
-
768CR-77263-00-00 LINING, SHROUD 3LINING, SHROUD 3
-
778CR-77265-00-00 LINING, SHROUD 5LINING, SHROUD 5
-
788CR-77266-00-00 LINING, SHROUD 6LINING, SHROUD 6
-
798CR-77267-01-00 LINING, SHROUD 7LINING, SHROUD 7
-
808CR-77269-00-00 LINING, SHROUD 9LINING, SHROUD 9
-
818CR-77271-00-00 DAMPER, NOISE 1DAMPER, NOISE 1
-
828CR-7717J-00-00 TAPE, 5TAPE, 5
-
838CR-77165-00-00 TRIM 1TRIM 1
-
848DJ-7717J-00-00 TAPE, 5TAPE, 5
-
858CY-77351-00-00 EMBLEM 1EMBLEM 1
-
868CY-77352-00-00 EMBLEM 2EMBLEM 2
-
878CW-W2196-02-00 PANEL, SUB-FRAME KITPANEL, SUB-FRAME KIT
-
888CW-21916-02-00 ...PANEL, SUB FRAME 5...PANEL, SUB FRAME 5
-
898CW-21943-00-00 ...BRACKET, MAIN TRACK 1...BRACKET, MAIN TRACK 1
-
908CW-21964-02-00 ...PATCH 4...PATCH 4
-
918CW-21965-02-00 ...PATCH 5...PATCH 5
-
9290267-47186-00 ...RIVET, BLIND (UN)...RIVET, BLIND (UN)
-
938DM-27431-00-00 FOOTREST, REAR 1FOOTREST, REAR 1
-
948DM-27441-00-00 FOOTREST, REAR 2FOOTREST, REAR 2
-
9597707-50020-00 SCREW, TAPPINGSCREW, TAPPING
-
968DX-77141-00-00 EMBLEM 1EMBLEM 1
-
978CY-77762-00-00 LABEL, WARNING 2LABEL, WARNING 2
-
988CS-2197C-00-00 PROTECTOR, FRAME 3 (AP)PROTECTOR, FRAME 3 (AP)
-
9990267-48141-00 RIVET, BLIND (AP)RIVET, BLIND (AP)
