HYDRAULIC BRAKE ASSEMBLY для Arctic Cat 700 H1 EFI (SILVER) [A2008IBT4EUSL] - 2008 года выпуска
-
№АртикулНазвание
-
11502-015 HOSE, BRAKE - ASSEMBLYHOSE, BRAKE - ASSEMBLY
-
28476-625 SCREW, MACH-TSTRH M6X1.0X25 Z & YSCREW, MACH-TSTRH M6X1.0X25 Z & Y
-
38408-821 SCREW, CAP-HFH M8X1.25X20 CL8.8 W/2353SCREW, CAP-HFH M8X1.25X20 CL8.8 W/2353
-
40502-878 KIT-CALIPER, FULL ASSY - RIGHT FRONT (INC. 5-11)KIT-CALIPER, FULL ASSY - RIGHT FRONT (INC. 5-11)
-
40502-879 KIT-CALIPER,FULL ASSY - LEFT FRONT (INC. 5-11)KIT-CALIPER,FULL ASSY - LEFT FRONT (INC. 5-11)
-
50502-603 ...KIT-HOUSING, PISTONS, SEALS, BLEADER - RIGHT FRONT (INC. 6-8)...KIT-HOUSING, PISTONS, SEALS, BLEADER - RIGHT FRONT (INC. 6-8)
-
50502-611 ...KIT-HOUSING, PISTONS, SEALS, BLEADER - LEFT FRONT (INC. 6-8)...KIT-HOUSING, PISTONS, SEALS, BLEADER - LEFT FRONT (INC. 6-8)
-
60502-606 ......SET, PISTONS/SEALS (INC. 7)......SET, PISTONS/SEALS (INC. 7)
-
70502-607 ......SET, SEALS-CALIPER......SET, SEALS-CALIPER
-
80502-609 ......VALVE, BLEED......VALVE, BLEED
-
90502-608 ...O-RING, GUIDE - SET...O-RING, GUIDE - SET
-
100502-605 ...BRACKET ASSEMBLY...BRACKET ASSEMBLY
-
110502-875 ...KIT-PAD, BRAKE-SET (TYPE 97)...KIT-PAD, BRAKE-SET (TYPE 97)
-
120423-178 WASHER, CRUSHWASHER, CRUSH
-
130423-413 BOLT, BANJO-FITTINGBOLT, BANJO-FITTING
-
140623-038 NUT W/WASHERNUT W/WASHER
