FUEL PUMP ASSEMBLY для Arctic Cat M 9000 HCR 162 (GREEN) [S2015M9NHCUSG] - 2015 года выпуска
-
№АртикулНазвание
-
10423-898 SCREW,TSPH-THRD FORM M5X0.8X20MM SEMSSCREW,TSPH-THRD FORM M5X0.8X20MM SEMS
-
22670-042 MOUNT,FUEL PUMPMOUNT,FUEL PUMP
-
32670-474 PUMP,FUEL-TURBO S/P (INC. 4)PUMP,FUEL-TURBO S/P (INC. 4)
-
42670-235 ...FLOAT,FUEL PUMP-WALBRO 75-22...FLOAT,FUEL PUMP-WALBRO 75-22
-
50470-838 SEAL,FUEL-PUMPSEAL,FUEL-PUMP
-
62670-377 PICKUP, FUEL - 3MPPICKUP, FUEL - 3MP
-
70610-563 CLAMP, HOSE-13.2MM-15.7MMCLAMP, HOSE-13.2MM-15.7MM
-
82670-442 HOSE, FUEL PUMP/PICKUPHOSE, FUEL PUMP/PICKUP
-
91670-878 FITTING,QUICK CONNECTOR-3/8X5/16X90 DEGFITTING,QUICK CONNECTOR-3/8X5/16X90 DEG
-
100610-876 HOSE, GASLINE - PUMP/FILTERHOSE, GASLINE - PUMP/FILTER
-
111670-825 FILTER, FUELFILTER, FUEL
-
120123-788 TIE, CABLE - 8 IN.TIE, CABLE - 8 IN.
-
120623-751 TIE, CABLE - REUSABLETIE, CABLE - REUSABLE
-
138061-706 RIVET,BLIND-LF SS64 (BLACK)RIVET,BLIND-LF SS64 (BLACK)
-
142670-339 BRACKET, MOUNTING - FUEL FILTERBRACKET, MOUNTING - FUEL FILTER
-
150610-874 HOSE, GASLINE - FILTER/THROTTLE BODYHOSE, GASLINE - FILTER/THROTTLE BODY
-
160619-776 CONDUIT - 5 FT (OPTIONAL)CONDUIT - 5 FT (OPTIONAL)
-
170623-373 CLAMP,HOSE #4 {6202}CLAMP,HOSE #4 {6202}
-
180610-415 CLAMP,HOSE-10.8 MM TO 13.3 MMCLAMP,HOSE-10.8 MM TO 13.3 MM
-
192670-330 HOSE, GASLINE - RETURNHOSE, GASLINE - RETURN
