REAR SUSPENSION FRONT ARM SHOCK ABSORBER для Arctic Cat ZR 8000 RR ES 137 GREEN EARLY BUILD - 2018 года выпуска
-
№АртикулНазвание
-
12704-966 COMPLETE SHOCK ABSORBER (INC. 2-11)COMPLETE SHOCK ABSORBER (INC. 2-11)
-
23603-520 ...KNOB, DAMPING ADJUSTER - REBOUND...KNOB, DAMPING ADJUSTER - REBOUND
-
33603-377 ...SCREW, MACHINE...SCREW, MACHINE
-
43603-026 ...PRELOAD RING...PRELOAD RING
-
53603-027 ...PRELOAD RING, BACK-UP...PRELOAD RING, BACK-UP
-
63603-523 ...DECAL, BASE VALUE...DECAL, BASE VALUE
-
73603-562 ...DECAL, RESERVOIR...DECAL, RESERVOIR
-
83603-365 ...DECAL, "PERFORMANCE SERIES"...DECAL, "PERFORMANCE SERIES"
-
93604-530 ...BUMPER...BUMPER
-
100403-490 ...RETAINER, SPRING...RETAINER, SPRING
-
113603-522 ...KIT, SEAL/CAP REBUILD...KIT, SEAL/CAP REBUILD
-
123704-035 SPRING, COMPRESSION - BLACKSPRING, COMPRESSION - BLACK
-
134604-238 RING, COMMUNICATORRING, COMMUNICATOR
-
143704-039 SPRING, COMPRESSION - BLACKSPRING, COMPRESSION - BLACK
-
152623-202 NUT, LOCK W/WASHERNUT, LOCK W/WASHER
-
163604-906 BEARINGBEARING
-
174604-228 AXLE, SHOCKAXLE, SHOCK
-
188408-045 SCREW, CAPSCREW, CAP
-
195639-530 OIL, SHOCK - 1 QTOIL, SHOCK - 1 QT
