CRANKCASE для Kawasaki ZR-7S - 2001 года выпуска
-
№АртикулНазвание
-
132132Y0620 BOLT, FLANGED, SMALLBOLT, FLANGED, SMALL
-
221221B0620 SCREW, CSK, CROS, 6X20SCREW, CSK, CROS, 6X20
-
670670E3046 O-RING, 46MMO-RING, 46MM
-
1400114001-5370 SET, CRANKCASESET, CRANKCASE
-
1401314013-004 RING, POSITIONRING, POSITION
-
1401414014-1007 PLATE, POSITION, SECONDARY SHAFTPLATE, POSITION, SECONDARY SHAFT
-
2701027010-1313 SWITCH, OIL PRESSURESWITCH, OIL PRESSURE
-
9200492004-1231 STUD, 10X133STUD, 10X133
-
92004A92004-1232 STUD, 10X153STUD, 10X153
-
92004B92004-1233 STUD, 10X116STUD, 10X116
-
9203792037-1069 CLAMP, L=60CLAMP, L=60
-
9204392043-1037 PIN, DOWEL, 10X14PIN, DOWEL, 10X14
-
9205592055-1146 O-RINGO-RING
-
9206292062-014 NOZZLENOZZLE
-
92062A92062-016 NOZZLENOZZLE
-
92062B92062-1081 NOZZLE, 6X8 (SILVER)NOZZLE, 6X8 (SILVER)
-
92062C92062-1086 NOZZLE, 5X6 (SILVER)NOZZLE, 5X6 (SILVER)
-
9206692066-057 PLUG, RUBBER BALL, 6.7PLUG, RUBBER BALL, 6.7
-
92066A92066-1005 PLUGPLUG
-
92066B92066-1019 PLUG, SECONDARY SHAFT, 52X19PLUG, SECONDARY SHAFT, 52X19
-
92066C92066-1096 PLUG, MAIN GALLERY, 18X9 (BLACK)PLUG, MAIN GALLERY, 18X9 (BLACK)
