FRAME FITTINGS для Kawasaki Vulcan 1600 Classic - 2005 года выпуска
-
№АртикулНазвание
-
130130J0616 BOLT-FLANGED, 6X16 (BLACK)BOLT-FLANGED, 6X16 (BLACK)
-
1105211052-1234 BRACKET, SIDE COVER LOCKBRACKET, SIDE COVER LOCK
-
1105311053-0143 BRACKET, HELMET LOCKBRACKET, HELMET LOCK
-
11053A11053-0289 BRACKET, BATTERY BANDBRACKET, BATTERY BAND
-
11053B11053-0434 BRACKET, REGULATORBRACKET, REGULATOR
-
1409114091-0054 COVER, HEAD PIPE (RIGHT)COVER, HEAD PIPE (RIGHT)
-
14091A14091-0092 COVER, HEAD PIPE (LEFT)COVER, HEAD PIPE (LEFT)
-
14091B14091-0380 COVER, FENDER (LEFT)COVER, FENDER (LEFT)
-
14091C14091-0381 COVER, FENDER (RIGHT)COVER, FENDER (RIGHT)
-
3209732097-1192 CASE-BATTERYCASE-BATTERY
-
3209832098-1137 CASE-TOOLCASE-TOOL
-
4203642036-1330 SLEEVE, L=45SLEEVE, L=45
-
9200292002-1700 BOLT, 6X14BOLT, 6X14
-
9202292022-183 WASHER, 6.2X11X1.5WASHER, 6.2X11X1.5
-
92022A92022-3043 WASHER, PLAIN, 8MMWASHER, PLAIN, 8MM
-
9204692046-1202 BEARING-NEEDLE, BM2824BEARING-NEEDLE, BM2824
-
9204992049-1181 SEAL-OILSEAL-OIL
-
9207292072-1331 BAND, L=470BAND, L=470
-
9207592075-1067 DAMPERDAMPER
-
92075A92075-1629 DAMPERDAMPER
-
9214392143-1878 COLLAR, 20.2X27X90COLLAR, 20.2X27X90
-
9215092150-1133 BOLT, 6X14BOLT, 6X14
-
92150A92150-1198 BOLT, 6X16BOLT, 6X16
-
9215192151-1438 BOLT, 8X14BOLT, 8X14
-
9215392153-0419 BOLT, SOCKET, 8X35BOLT, SOCKET, 8X35
-
92153A92153-0420 BOLT, SOCKET, 8X50BOLT, SOCKET, 8X50
-
9216192161-1097 DAMPER, BATTERYDAMPER, BATTERY
-
92161A92161-1214 DAMPER, BATTERY BANDDAMPER, BATTERY BAND
-
9217292172-0005 SCREW, 6X10SCREW, 6X10
-
9221092210-0003 NUT, CAP, 6MMNUT, CAP, 6MM
