REAR BRAKE CALIPER для Ktm 690 ENDURO R - 2018 года выпуска
-
№АртикулНазвание
-
17601308000101 BRAKE CAL. RE. - WITHOUT PADSBRAKE CAL. RE. - WITHOUT PADS
-
27601317500001 BRAKE CALIPER BRACKET REARBRAKE CALIPER BRACKET REAR
-
354613311200 RETAINING SPRING SETRETAINING SPRING SET
-
454613218000 CUP SET SHORTCUP SET SHORT
-
561013020200 BLEEDER SCREW WITH CAPBLEEDER SCREW WITH CAP
-
750313083000 BRAKE PISTON 32MMBRAKE PISTON 32MM
-
850313081000 REPAIR KIT SEALING RINGS 32MMREPAIR KIT SEALING RINGS 32MM
-
1175013090000 BRAKE PAD SET REAR SBS-S-40GFBRAKE PAD SET REAR SBS-S-40GF
-
1261013082000 BOLT SETBOLT SET
-
1362113020100 HOLL. SCREW M10X1X19.5HOLL. SCREW M10X1X19.5
-
140603100141 COPPER GASKET DIN7603-10X14X1COPPER GASKET DIN7603-10X14X1
-
1576542001000 BRAKE HOSE REAR CALIPERBRAKE HOSE REAR CALIPER
