THROTTLE LINKAGE (MANUAL) для Mercury - 9.9 (4-STROKE)(232 cc) 0H000058 THRU 0H016909
-
№АртикулНазвание
-
1825792 SHIFT HANDLE
SIDE SHIFTSHIFT HANDLE
SIDE SHIFT -
225-825781 GROMMET
SIDE SHIFTGROMMET
SIDE SHIFT -
310-82239312 SCREW (M5 X 12)
SIDE SHIFTSCREW (M5 X 12)
SIDE SHIFT -
48280471 STRAPSTRAP
-
510-4006731 SCREW (M6 X 16)SCREW (M6 X 16)
-
610-8M4503518 SCREW (M6 X 20)SCREW (M6 X 20)
-
712-4002316 WASHERWASHER
-
8830880 LINK-SLIDINGLINK-SLIDING
-
9826065 LINK-JOINTLINK-JOINT
-
1011-8237515 NUTNUT
-
11825790 THROTTLE LINKTHROTTLE LINK
-
12826137 LINK-JOINTLINK-JOINT
-
13825787A2 PULLEYPULLEY
-
1423-825788 BUSHING (SIDE SHIFT)BUSHING (SIDE SHIFT)
-
1511-401196 NUTNUT
-
1624-824992 SPRINGSPRING
-
1724-824993 SPRINGSPRING
-
18824994 PLATEPLATE
-
1910-82239312 SCREW (M5 X 12)SCREW (M5 X 12)
-
2010-40011111 SCREW (M5 X 35)SCREW (M5 X 35)
-
21826063 INTERLOCK LEVERINTERLOCK LEVER
-
22852494A5 HORIZONTAL SHIFT SHAFTHORIZONTAL SHIFT SHAFT
-
2310-8M4503518 SCREW (M6 X 20) (SIDE SHIFT)SCREW (M6 X 20) (SIDE SHIFT)
-
248257863 CONTROL PLATFORMCONTROL PLATFORM
-
2523-825789 BUSHING (SIDE SHIFT)BUSHING (SIDE SHIFT)
-
26826037 PLUG
HANDLE SHIFTPLUG
HANDLE SHIFT -
27826021 GEAR-DRIVEN
HANDLE SHIFTGEAR-DRIVEN
HANDLE SHIFT -
28826022 COVER
HANDLE SHIFTCOVER
HANDLE SHIFT -
2910-8M4503518 SCREW (M6 X 20)
HANDLE SHIFTSCREW (M6 X 20)
HANDLE SHIFT -
30826019 GEAR-DRIVER
HANDLE SHIFTGEAR-DRIVER
HANDLE SHIFT
