HOOD - FOAM/FOIL для Polaris INDY 340 TOURING (S02LT3AS) - 2002 года выпуска
-
№АртикулНазвание
-
17512103 BOLTBOLT
-
27080414 CABLE, HOOD RETAINERCABLE, HOOD RETAINER
-
37542122 NUT, NYLOCKNUT, NYLOCK
-
47555806 WASHER, FLATWASHER, FLAT
-
57670017 PUSH, ON NUTPUSH, ON NUT
-
65243932 DEFLECTOR, AIR LITEDEFLECTOR, AIR LITE
-
75243629-067 SCREEN, HOOD (UPPER) (BLACK)SCREEN, HOOD (UPPER) (BLACK)
-
85243628-067 SCREEN, HOOD (CENTER) (BLACK)SCREEN, HOOD (CENTER) (BLACK)
-
95243627-067 SCREEN, HOOD (LOWER) (BLACK)SCREEN, HOOD (LOWER) (BLACK)
-
107670082 SPEEDCLIP, 'U'TYPESPEEDCLIP, 'U'TYPE
-
115811772 FOAM, HOOD (LEFT)FOAM, HOOD (LEFT)
-
125811563 FOIL, HOOD #2 (RIGHT)FOIL, HOOD #2 (RIGHT)
-
135811773 FOAM, HOOD PSA1 (RIGHT)FOAM, HOOD PSA1 (RIGHT)
-
147670040 CLIP, U TYPECLIP, U TYPE
-
155243630-067 SCREEN, HOOD SIDE (BLACK)SCREEN, HOOD SIDE (BLACK)
