SEAT W/ GAS TANK ASSEMBLY для Polaris 600 RMK 144 (S03NK6ES) - 2003 года выпуска

№

Артикул

Название
1

1240066 CAP FUEL, 12 GAL W/GAUGE

CAP FUEL, 12 GAL W/GAUGE

8 950 ₽
2

2683036 SEAT, EDGE ASSY (INCL. 2, 5) (STD RMK)

SEAT, EDGE ASSY (INCL. 2, 5) (STD RMK)

114 400 ₽
2

2683037 SEAT COVER, EDGE RMK ASSY

SEAT COVER, EDGE RMK ASSY

0 ₽
3

7558301 WASHER, FLAT

WASHER, FLAT

110 ₽
4

7517219 SCREW

SCREW

670 ₽
5

2461064 HARNESS TAILLIGHT, SEAT

HARNESS TAILLIGHT, SEAT

12 480 ₽
6

7542122 NUT NYLOK

NUT NYLOK

110 ₽
7

7555960 WASHER, FLAT

WASHER, FLAT

630 ₽
8

7670021 NUT, SPEED

NUT, SPEED

460 ₽
9

7512193 BOLT, CARRIAGE

BOLT, CARRIAGE

630 ₽
10

5810947 FOAM, SEAL

FOAM, SEAL

460 ₽
11

8350017-600 FUEL, LINE ETHER 5/16 (RED)

FUEL, LINE ETHER 5/16 (RED)

0 ₽
12

7080003 CLAMP, HOSE

CLAMP, HOSE

110 ₽
13

7052269 FITTING, 5/16"/ 3/8 STRAIGHT

FITTING, 5/16"/ 3/8 STRAIGHT

3 120 ₽
14

5432981 GROMMET 1-1/2" NITRILLE

GROMMET 1-1/2" NITRILLE

1 310 ₽
15

7080768 RING, COMPRESSION

RING, COMPRESSION

1 250 ₽
16

8350020-600 FUEL, LINE ETHER VLT 3/8"

FUEL, LINE ETHER VLT 3/8"

5 620 ₽
17

7052215 PICK-UP, FUEL W/MESH

PICK-UP, FUEL W/MESH

6 660 ₽
18

2520262 FUEL TANK ASSY

FUEL TANK ASSY

49 920 ₽
19

7052095 FITTING, 90 DEG

FITTING, 90 DEG

750 ₽
20

8450061-600 LINE, FUEL (3MMX7MM)

LINE, FUEL (3MMX7MM)

10 400 ₽
