FRAME для Suzuki DR-Z110K5 - 2005 года выпуска
-
№АртикулНазвание
-
32160K3216-01773-466 FRAME-COMP,M.F.GRAYFRAME-COMP,M.F.GRAY
-
46098KK460-98018 CAP,STEERING STEMCAP,STEERING STEM
-
92015K9201-51222 NUT,STEERING LOCK,25MMNUT,STEERING LOCK,25MM
-
92047KK920-47014 CONE,STEERING STEM BEARINGCONE,STEERING STEM BEARING
-
92048KK920-48009 RACE,STEERING STEM BEARINGRACE,STEERING STEM BEARING
-
600KK600-A0600 BALL-STEEL,3/16''BALL-STEEL,3/16''
Все узлы модели:
- ACCESSORY - NUMBER PLATE
- AIR CLEANER
- BRAKE PEDAL
- BRAKE PEDAL W/ STAND
- CABLES
- CAMSHAFT W/ TENSIONER
- CARBURETOR ASSY.
- CLUTCH
- CRANKCASE
- CRANKSHAFT W/ PISTON
- CYLINDER HEAD
- CYLINDER/PISTON
- DECAL
- ELECTRICAL - MAIN HARNESS
- ENGINE COVERS
- ENGINE GUARD
- ENGINE MOUNT
- FENDERS - FRONT/REAR
- FOOTREST
- • FRAME
- FRONT HUB W/ BRAKES
- FUEL TANK
- GEAR CHANGE DRUM/SHIFT FORK
- GEAR CHANGE MECHANISM
- GENERATOR
- HANDLEBAR
- IGNITION SYSTEM
- KICKSTARTER
- LABEL
- MUFFLER
- OIL PUMP
- OWNER'S TOOL
- REAR HUB W/ BRAKE
- SEAT
- SIDE COVER W/ CHAIN COVER
- SUSPENSION - FRONT FORK
- SUSPENSION - REAR SUSPENSION - MOUNTING
- SUSPENSION - REAR SWING ARM
- SUSPENSION - SHOCK ABSORBER
- TRANSMISSION
- VALVE
- WHEEL AND TIRES
