GENERATOR для Suzuki DR-Z110K5 - 2005 года выпуска
-
№АртикулНазвание
-
13270K1327-01754 PLATEPLATE
-
13270AK1327-01961 PLATEPLATE
-
21003K2100-31390 STATORSTATOR
-
21007K2100-71408 ROTORROTOR
-
21066K2106-61086 REGULATOR-VOLTAGEREGULATOR-VOLTAGE
-
21119K2111-91612 IGNITERIGNITER
-
220KK220-B0514 SCREW-PAN-CROSSCREW-PAN-CROS
-
220AKK220-B0608 SCREW-PAN-CROS,6X8SCREW-PAN-CROS,6X8
-
220BKK220-B0614 SCREW-PAN-CROS,6X14SCREW-PAN-CROS,6X14
-
220CKK220-B0625 SCREW-PAN-CROS,6X25SCREW-PAN-CROS,6X25
Все узлы модели:
- ACCESSORY - NUMBER PLATE
- AIR CLEANER
- BRAKE PEDAL
- BRAKE PEDAL W/ STAND
- CABLES
- CAMSHAFT W/ TENSIONER
- CARBURETOR ASSY.
- CLUTCH
- CRANKCASE
- CRANKSHAFT W/ PISTON
- CYLINDER HEAD
- CYLINDER/PISTON
- DECAL
- ELECTRICAL - MAIN HARNESS
- ENGINE COVERS
- ENGINE GUARD
- ENGINE MOUNT
- FENDERS - FRONT/REAR
- FOOTREST
- FRAME
- FRONT HUB W/ BRAKES
- FUEL TANK
- GEAR CHANGE DRUM/SHIFT FORK
- GEAR CHANGE MECHANISM
- • GENERATOR
- HANDLEBAR
- IGNITION SYSTEM
- KICKSTARTER
- LABEL
- MUFFLER
- OIL PUMP
- OWNER'S TOOL
- REAR HUB W/ BRAKE
- SEAT
- SIDE COVER W/ CHAIN COVER
- SUSPENSION - FRONT FORK
- SUSPENSION - REAR SUSPENSION - MOUNTING
- SUSPENSION - REAR SWING ARM
- SUSPENSION - SHOCK ABSORBER
- TRANSMISSION
- VALVE
- WHEEL AND TIRES
