RADIATOR для Suzuki GSX-1250 FA L1 (CANADA) - 2011 года выпуска
-
№АртикулНазвание
-
117710-18H10 RADIATOR ASSY, WATERRADIATOR ASSY, WATER
-
217781-18H10 CUSHIONCUSHION
-
317800-18H10 FAN ASSY, RADIATORFAN ASSY, RADIATOR
-
417800-18H20 FAN ASSY, RADIATORFAN ASSY, RADIATOR
-
517802-14F00 NUTNUT
-
609320-10051 CUSHIONCUSHION
-
701550-0616A BOLTBOLT
-
817740-18H10 BRACKET, UPPERBRACKET, UPPER
-
917750-18H10 BRACKET, LOWERBRACKET, LOWER
-
1017771-18H00 SHIELD, HEATSHIELD, HEAT
-
1109116-06176 BOLT (6X37)BOLT (6X37)
-
1209118-06097 BOLT (6X25)BOLT (6X25)
-
1309180-06290 SPACER (6.5X10X12)SPACER (6.5X10X12)
-
1409407-14403 CLAMP (L:125)CLAMP (L:125)
-
1509407-18402 CLAMP (L:165)CLAMP (L:165)
-
1601550-0620A BOLTBOLT
-
1717680-48E00 SWITCH, RADIATOR FAN (INCL. 18)SWITCH, RADIATOR FAN (INCL. 18)
-
1817689-48E00 O RINGO RING
-
1909407-17403 CLAMP (L:154)CLAMP (L:154)
