BRAKE для Yamaha DRIVE2 PTV (DR2A17PTV SERIAL: J0D-000101) - 2017 года выпуска
-
№АртикулНазвание
-
1JW8-F7280-00-00 BACKING PLATE ASSY 1BACKING PLATE ASSY 1
-
2JN9-W2536-00-00 ...BRAKE SHOE SET...BRAKE SHOE SET
-
3J38-27204-00-00 ...LEVER ASSY 1...LEVER ASSY 1
-
4JW8-F7281-00-00 ...SPRING, SHOE CLAMP...SPRING, SHOE CLAMP
-
5J10-27282-00-00 ...PIN, SHOE HOLD DOWN...PIN, SHOE HOLD DOWN
-
690506-20281-00 ...SPRING, TENSION...SPRING, TENSION
-
790506-14001-00 ...SPRING, TENSION...SPRING, TENSION
-
8J55-27270-00-00 ...ADJUSTER ASSY...ADJUSTER ASSY
-
9JW8-F7286-00-00 ...COVER, DUST...COVER, DUST
-
1090201-121H9-00 ...WASHER, PLATE...WASHER, PLATE
-
1190201-121H8-00 ...WASHER, PLATE...WASHER, PLATE
-
12JW8-F7290-00-00 BACKING PLATE ASSY 2BACKING PLATE ASSY 2
-
13JN9-W2536-00-00 ...BRAKE SHOE SET...BRAKE SHOE SET
-
14J38-27205-00-00 ...LEVER ASSY 2...LEVER ASSY 2
-
15JW8-F7281-00-00 ...SPRING, SHOE CLAMP...SPRING, SHOE CLAMP
-
16J10-27282-00-00 ...PIN, SHOE HOLD DOWN...PIN, SHOE HOLD DOWN
-
1790506-20281-00 ...SPRING, TENSION...SPRING, TENSION
-
1890506-14001-00 ...SPRING, TENSION...SPRING, TENSION
-
19J55-27260-00-00 ...ADJUSTER ASSY...ADJUSTER ASSY
-
20JW8-F7286-00-00 ...COVER, DUST...COVER, DUST
-
2190201-121H9-00 ...WASHER, PLATE...WASHER, PLATE
-
2290201-121H8-00 ...WASHER, PLATE...WASHER, PLATE
-
2390105-082A0-00 BOLT, FLANGEBOLT, FLANGE
