AUXILIARY BRAKE ASSEMBLY для Arctic Cat 250 UTILITY (RED) [A2009KUE2BUSR] - 2009 года выпуска
-
№АртикулНазвание
-
13303-926 LEVER, BRAKELEVER, BRAKE
-
23304-139 WASHERWASHER
-
33304-143 PIN, COTTERPIN, COTTER
-
43303-855 SPRING, STOP - BRAKE LEVERSPRING, STOP - BRAKE LEVER
-
53303-929 SPRING, SET - BRAKE LEVERSPRING, SET - BRAKE LEVER
-
63303-854 SWITCH, BRAKESWITCH, BRAKE
-
73303-927 PIN, CLEVISPIN, CLEVIS
-
83304-050 WASHERWASHER
-
93304-141 PIN, COTTERPIN, COTTER
-
103304-306 BRAKE ASSEMBLY - REAR (INC. 11-20)BRAKE ASSEMBLY - REAR (INC. 11-20)
-
113303-928 ...ACTUATOR, PUSH ROD...ACTUATOR, PUSH ROD
-
123304-128 ...NUT...NUT
-
143303-321 ...SCREW W/WASHER...SCREW W/WASHER
-
153304-307 ...CONNECTOR...CONNECTOR
-
163303-895 ...CLAMP, HOSE...CLAMP, HOSE
-
173304-308 ...HOSE, BRAKE...HOSE, BRAKE
-
183303-896 ...RESERVOIR, BRAKE...RESERVOIR, BRAKE
-
193304-332 ...COVER, BRAKE RESERVOIR...COVER, BRAKE RESERVOIR
-
203304-119 ...SCREW, MACHINE...SCREW, MACHINE
-
213304-551 SCREW, CAPSCREW, CAP
-
223303-284 WASHER, CRUSHWASHER, CRUSH
-
233303-257 BOLT, BANJO-FITTINGBOLT, BANJO-FITTING
-
243303-889 HOSE, BRAKEHOSE, BRAKE
-
253303-891 CLAMP, RETAININGCLAMP, RETAINING
