IDLER WHEEL ASSEMBLY для Arctic Cat BEARCAT 2000 LT (INTERNATIONAL) (BLUE) [S2015BCDFCOSL] - 2015 года выпуска

№

Артикул

Название
1

1604-952 CAP, IDLER WHEEL

CAP, IDLER WHEEL

2 070 ₽
2

8408-880 SCREW,CAP-HFH M8X1.25X80 CL8.8 Z & Y

SCREW,CAP-HFH M8X1.25X80 CL8.8 Z & Y

250 ₽
3

8450-133 WASHER,FLAT-M8-9.12 X 25.40 X 2.30Z & Y

WASHER,FLAT-M8-9.12 X 25.40 X 2.30Z & Y

60 ₽
4

3604-299 WHEEL, IDLER - (WHITE) (INC. 5-6)

WHEEL, IDLER - (WHITE) (INC. 5-6)

7 900 ₽
5

3604-033 ......BEARING,WHL-NSK CHINA 6004-W/ENS GREASE

......BEARING,WHL-NSK CHINA 6004-W/ENS GREASE

3 110 ₽
6

0623-946 ......RING,INTERNAL RETAINING-#165

......RING,INTERNAL RETAINING-#165

310 ₽
7

3604-004 BLOCK, MOUNTING - IDLER WHEEL

BLOCK, MOUNTING - IDLER WHEEL

4 360 ₽
8

8408-830 SCREW,CAP-HFH M8X1.25X30 CL8.8 Z & Y

SCREW,CAP-HFH M8X1.25X30 CL8.8 Z & Y

150 ₽
9

8427-802 NUT,HEX FLG-NYL LOCK M8X1.25 CL8 Z & Y

NUT,HEX FLG-NYL LOCK M8X1.25 CL8 Z & Y

90 ₽
10

1423-064 BOLT, HFH M10-1.25X250 CL10.9 RIE (SILVER)

BOLT, HFH M10-1.25X250 CL10.9 RIE (SILVER)

1 020 ₽
11

3604-083 SPACER,FRONT ARM SHOCK

SPACER,FRONT ARM SHOCK

1 870 ₽
12

0623-912 WASHER, FLAT - 0.890 X 1.19 X 0.060 Z & Y

WASHER, FLAT - 0.890 X 1.19 X 0.060 Z & Y

150 ₽
13

3604-269 AXLE,ALUM-22.2 X 222.2

AXLE,ALUM-22.2 X 222.2

8 940 ₽
14

1623-992 WASHER, INTERNAL TOOTH LOCK

WASHER, INTERNAL TOOTH LOCK

40 ₽
15

8422-002 NUT,HEX-THK NYL M10X1.25 CL8 Z & Y

NUT,HEX-THK NYL M10X1.25 CL8 Z & Y

150 ₽
16

3604-039 WHEEL, IDLER (INC. 5-6)

WHEEL, IDLER (INC. 5-6)

7 900 ₽
17

3604-285 AXLE,REAR ARM-INNER-M10X155.5

AXLE,REAR ARM-INNER-M10X155.5

2 490 ₽
18

3604-325 SPACER, AUX WHEEL-INSIDE

SPACER, AUX WHEEL-INSIDE

5 610 ₽
19

1704-674 PIVOT, SHOCK (INC. 20)

PIVOT, SHOCK (INC. 20)

6 230 ₽
20

1623-010 ...FITTING,GREASE-1/4-28 UNF-SELF THREAD

...FITTING,GREASE-1/4-28 UNF-SELF THREAD

290 ₽
21

1623-794 WASHER,FLAT-.631 X 1.000 X .063 Z & Y

WASHER,FLAT-.631 X 1.000 X .063 Z & Y

150 ₽
22

3604-327 BLOCK, MOUNTING - IDLER WHEEL

BLOCK, MOUNTING - IDLER WHEEL

4 360 ₽
23

1704-279 SPRING, TRIPLE OVERLOAD ASSY-SLOTTED (INC. 24-27)

SPRING, TRIPLE OVERLOAD ASSY-SLOTTED (INC. 24-27)

17 470 ₽
24

2604-788 ...BLOCK,WEAR-SPRING SLIDE - .19 HOLE

...BLOCK,WEAR-SPRING SLIDE - .19 HOLE

3 740 ₽
25

0623-121 ...SCREW,MACH-PHTRH #10-32X3/4 Z & Y

...SCREW,MACH-PHTRH #10-32X3/4 Z & Y

730 ₽
26

8041-276 ...NUT,HEX THIN LOCK-NYL 10-32 Z & Y

...NUT,HEX THIN LOCK-NYL 10-32 Z & Y

40 ₽
27

1604-412 ...CLIP,RETAINING H.D.-SLOTTED

...CLIP,RETAINING H.D.-SLOTTED

6 650 ₽
28

0623-746 WASHER,2.00X.386X.1046

WASHER,2.00X.386X.1046

310 ₽
29

0604-739 BUSHING, OVERLOAD SPRING

BUSHING, OVERLOAD SPRING

650 ₽
30

1604-430 SPACER, SPRING SLIDE

SPACER, SPRING SLIDE

2 700 ₽
31

2604-516 SLIDE, SPRING-TALL

SLIDE, SPRING-TALL

920 ₽
32

1704-680 BUSHING, ADJUSTER

BUSHING, ADJUSTER

1 870 ₽
33

3604-060 WHEEL, IDLER (INC. 5-6)

WHEEL, IDLER (INC. 5-6)

7 900 ₽
34

1604-940 SPACER,REAR WHEEL- 6.456 LG

SPACER,REAR WHEEL- 6.456 LG

2 280 ₽
35

3604-326 AXLE, REAR WHEEL

AXLE, REAR WHEEL

5 400 ₽
36

0623-921 WASHER, FLAT.788ID X 1.5OD X .109

WASHER, FLAT.788ID X 1.5OD X .109

250 ₽
37

8042-486 NUT,3/8-16 HEX-REG-GR5 Z & Y

NUT,3/8-16 HEX-REG-GR5 Z & Y

40 ₽
38

0124-310 HHCS 3/8-16X4.0 THREADED GR5 Z & Y

HHCS 3/8-16X4.0 THREADED GR5 Z & Y

380 ₽
39

3604-298 WHEEL, IDLER - (WHITE) (INC. 5-6)

WHEEL, IDLER - (WHITE) (INC. 5-6)

7 900 ₽
40

0623-664 WASHER,FLAT 1.00X.390X.164 Z & Y

WASHER,FLAT 1.00X.390X.164 Z & Y

190 ₽
41

8408-831 SCREW,CAP-HFH M8X1.25X30 CL8.8 W/2353

SCREW,CAP-HFH M8X1.25X30 CL8.8 W/2353

150 ₽
