SKID PLATE AND SIDE PANEL ASSEMBLY для Arctic Cat BEARCAT 2000 LT (INTERNATIONAL) (BLUE) [S2015BCDFCOSL] - 2015 года выпуска

№

Артикул

Название
1

4718-880 PANEL, SIDE - UPPER W/DECALS - RIGHT - (WHITE) (INC. 2-5)

PANEL, SIDE - UPPER W/DECALS - RIGHT - (WHITE) (INC. 2-5)

53 870 ₽
1

4718-881 PANEL, SIDE - UPPER W/DECALS - LEFT - (WHITE) (INC. 2-3 AND 5)

PANEL, SIDE - UPPER W/DECALS - LEFT - (WHITE) (INC. 2-3 AND 5)

51 990 ₽
2

2718-356 ...PANEL, SIDE - UPPER W/O DECALS - RIGHT - (WHITE) (INC. 3-4)

...PANEL, SIDE - UPPER W/O DECALS - RIGHT - (WHITE) (INC. 3-4)

39 310 ₽
2

2718-801 ...PANEL, SIDE - UPPER W/O DECALS - LEFT - (WHITE) (INC. 3)

...PANEL, SIDE - UPPER W/O DECALS - LEFT - (WHITE) (INC. 3)

39 310 ₽
3

0617-562 ......FOAM, UPPER SIDE PANEL - RIGHT

......FOAM, UPPER SIDE PANEL - RIGHT

6 860 ₽
3

0617-057 ......FOAM, UPPER SIDE PANEL - LEFT

......FOAM, UPPER SIDE PANEL - LEFT

1 020 ₽
4

0637-318 ...KIT, UPDATE - PROTECTIVE FOIL

...KIT, UPDATE - PROTECTIVE FOIL

360 ₽
5

1621-268 ...DECAL, UPPER SIDE PANEL - RIGHT

...DECAL, UPPER SIDE PANEL - RIGHT

3 740 ₽
5

1621-269 ...DECAL, UPPER SIDE PANEL - LEFT

...DECAL, UPPER SIDE PANEL - LEFT

3 740 ₽
6

4606-650 VENT, UPPER PANEL - REAR RIGHT - MOLD - (BLACK)

VENT, UPPER PANEL - REAR RIGHT - MOLD - (BLACK)

3 950 ₽
6

4606-651 VENT, UPPER PANEL - REAR LEFT - MOLD - (BLACK)

VENT, UPPER PANEL - REAR LEFT - MOLD - (BLACK)

3 950 ₽
7

5606-185 VENT, UPPER SIDE PANEL - CENTER - LEFT

VENT, UPPER SIDE PANEL - CENTER - LEFT

3 320 ₽
8

4606-662 VENT, UPPER SIDE PANEL - RIGHT - (BLACK)

VENT, UPPER SIDE PANEL - RIGHT - (BLACK)

3 110 ₽
8

4606-663 VENT, UPPER SIDE PANEL - LEFT - (BLACK)

VENT, UPPER SIDE PANEL - LEFT - (BLACK)

3 110 ₽
9

2718-274 PANEL, SIDE - LOWER - RIGHT - (BLACK) (INC. 10-12)

PANEL, SIDE - LOWER - RIGHT - (BLACK) (INC. 10-12)

44 510 ₽
9

2718-349 PANEL, SIDE - LOWER - LEFT - (BLACK) (INC. 10-11)

PANEL, SIDE - LOWER - LEFT - (BLACK) (INC. 10-11)

44 510 ₽
10

0617-567 ...FOAM, LOWER SIDE PANEL - REAR LEFT (19 MM THICK)

...FOAM, LOWER SIDE PANEL - REAR LEFT (19 MM THICK)

13 930 ₽
11

0617-566 ...FOAM, LOWER SIDE PANEL - FRONT - LEFT

...FOAM, LOWER SIDE PANEL - FRONT - LEFT

2 490 ₽
13

6606-219 FOIL, PROTECTIVE

FOIL, PROTECTIVE

690 ₽
14

6606-218 FOIL, PROTECTIVE

FOIL, PROTECTIVE

520 ₽
15

6606-220 FOIL, PROTECTIVE

FOIL, PROTECTIVE

960 ₽
16

0423-355 SCREW, SHOULDER-M6-1.0 X 18- (BLACK)

SCREW, SHOULDER-M6-1.0 X 18- (BLACK)

150 ₽
17

5606-404 DEFLECTOR, EXHAUST

DEFLECTOR, EXHAUST

2 280 ₽
18

8427-602 NUT,HEX FLG-NYL LOCK M6X1.0 CL8 Z & Y

NUT,HEX FLG-NYL LOCK M6X1.0 CL8 Z & Y

440 ₽
19

8408-620 SCREW,CAP-HFH M6X1.0X20 CL8.8 Z & Y

SCREW,CAP-HFH M6X1.0X20 CL8.8 Z & Y

110 ₽
20

8408-635 SCREW,CAP-HFH M6X1.0X35 CL8.8 Z & Y

SCREW,CAP-HFH M6X1.0X35 CL8.8 Z & Y

110 ₽
21

4606-926 STRAP, HOLD-DOWN

STRAP, HOLD-DOWN

710 ₽
22

5706-172 PLATE, SKID - RIGHT

PLATE, SKID - RIGHT

8 310 ₽
22

4706-073 PLATE, SKID - LEFT

PLATE, SKID - LEFT

8 520 ₽
23

6606-423 SHIELD, HEAT

SHIELD, HEAT

1 870 ₽
24

8061-506 RIVET,BLIND-LF SS54 (BLACK)

RIVET,BLIND-LF SS54 (BLACK)

150 ₽
25

4606-798 FOIL, PROTECTIVE

FOIL, PROTECTIVE

380 ₽
26

4606-797 FOIL, PROTECTIVE

FOIL, PROTECTIVE

650 ₽
27

8060-510 RIVET,BLIND-DH SS58 (BLACK)

RIVET,BLIND-DH SS58 (BLACK)

110 ₽
28

1712-348 PLATE, EXHAUST - OUTLET

PLATE, EXHAUST - OUTLET

2 280 ₽
29

2612-268 SHIELD,HEAT-RH SKID PLATE

SHIELD,HEAT-RH SKID PLATE

3 320 ₽
30

2612-287 SEAL, EXHAUST - OUTLET

SEAL, EXHAUST - OUTLET

2 490 ₽
31

8061-508 RIVET,BLIND-LF SS56 (BLACK)

RIVET,BLIND-LF SS56 (BLACK)

110 ₽
32

1712-501 SHIELD, HEAT - EXHAUST OUTLET - PAINTED

SHIELD, HEAT - EXHAUST OUTLET - PAINTED

4 780 ₽
33

0623-778 RIVET, BULBEX-BF01-0625

RIVET, BULBEX-BF01-0625

170 ₽
34

8061-708 RIVET, BLIND-LF SS66 (BLACK)

RIVET, BLIND-LF SS66 (BLACK)

150 ₽
35

0623-966 SCREW,SELF TAP-HWH M6 X 12 Z (TRI LOB)

SCREW,SELF TAP-HWH M6 X 12 Z (TRI LOB)

170 ₽
