11- Accessories для BRP Lynx Explorer 550 - 2004
-
№АртикулНазвание
-
7820240 CoverCover
-
572111209 Rewind handle, yellowRewind handle, yellow
-
5246214 Handle bar, lowHandle bar, low
-
502006554 Skid plate, purpleSkid plate, purple
-
572111211 Skid plate, yellowSkid plate, yellow
-
572111210 Skid plate, blackSkid plate, black
-
5147582 Skid plate, redSkid plate, red
-
5345294 PrimerPrimer
-
502006535 Bumber, yellowBumber, yellow
-
502006602 Bumber, redBumber, red
-
605158633 Skiliner, blackSkiliner, black
-
5248050 Electric starter kitElectric starter kit
-
861776900 R.H. Moulding (yellow)R.H. Moulding (yellow)
-
861777100 R.H. Moulding (red)R.H. Moulding (red)
-
861777000 L.H. Moulding (yellow)L.H. Moulding (yellow)
-
861777200 L.H. Moulding (red)L.H. Moulding (red)
-
7820267 Goods boxGoods box
-
504151935 Track (22,2)Track (22,2)
-
504152061 Track (25,4)Track (25,4)
-
504152028 Track (31,8)Track (31,8)
-
130004 Track (30), 60ShATrack (30), 60ShA
-
517302022 Windscreen, mediumWindscreen, medium
-
5146770 Windscreen, highWindscreen, high
-
517302002 Windscreen, lowWindscreen, low
-
5346664 Hitch kitHitch kit
-
605150325 Extra bumper kitExtra bumper kit
-
5348242 Tachometer assy, whiteTachometer assy, white
-
5347554 Current outletCurrent outlet
-
605348898 Shock, ski (36 mm)Shock, ski (36 mm)
-
605348903 Shock, center (46 mm)Shock, center (46 mm)
-
605348904 Shock, rear (46 mm)Shock, rear (46 mm)
-
605349418 Ski, SLPSki, SLP
