02- Air Intake Manifold And Throttle Body для BRP Ski-Doo 008 - RENEGADE 900 ACE Turbo - 2019
-
№АртикулНазвание
-
1>2420867342 Airbox Ass'yAirbox Ass'y
-
2420431662 GasketGasket
-
3420440647 Flanged Torx Screw M6 X 30Flanged Torx Screw M6 X 30
-
4715900392 Pressure/Temp sensorPressure/Temp sensor
-
5420841103 Flanged Torx Screw M6 X 20Flanged Torx Screw M6 X 20
-
6>8420874845 Injection ValveInjection Valve
-
7420831050 O-RingO-Ring
-
8420631220 O-RingO-Ring
-
9420853030 ClipClip
-
10420874966 Fuel RailFuel Rail
-
11420441573 Flanged Torx Screw M6 X 30Flanged Torx Screw M6 X 30
-
12420867110 Intake NeckIntake Neck
-
13420251830 Hose ClampHose Clamp
-
14420893148 Throttle BodyThrottle Body
-
15420441588 Flanged Torx Screw M6 X 50Flanged Torx Screw M6 X 50
-
16420867556 Connecting SocketConnecting Socket
-
17420274057 Pressure SensorPressure Sensor
-
18420641588 Flanged Torx Screw M6 X 16Flanged Torx Screw M6 X 16
-
19420201506 Molded HoseMolded Hose
-
20420201500 Molded HoseMolded Hose
-
21420853511 ClampClamp
-
22420951830 Double ClampDouble Clamp
