CARBURETOR ASSEMBLY для Polaris 700 XC SP EDGE X F/O (S03NA7CS) - 2003 года выпуска
-
№АртикулНазвание
-
13130951 SCREWSCREW
-
23130976 CAP (TOP)CAP (TOP)
-
33130871 GASKETGASKET
-
43130844 SCREWSCREW
-
53130846 WASHER, PACKINGWASHER, PACKING
-
63130856 CLIPCLIP
-
73130845 RINGRING
-
83130857 PLATEPLATE
-
93130847 E-RINGE-RING
-
103130831 CAP, RUBBERCAP, RUBBER
-
113130830 HOLDER, GUIDEHOLDER, GUIDE
-
123130829 SPRINGSPRING
-
133130828 PLUNGER ASSY (./258)PLUNGER ASSY (./258)
-
143130940 VALVE, PISTON (1.5)VALVE, PISTON (1.5)
-
153131415 NEEDLE JET J8-9DGN05-57NEEDLE JET J8-9DGN05-57
-
163130867 PACKINGPACKING
-
173130868 E-RINGE-RING
-
183130843 PLATEPLATE
-
193130855 LEVER ASSYLEVER ASSY
-
193130849 LEVER ASSYLEVER ASSY
-
203130848 RINGRING
-
213130854 SCREWSCREW
-
223130850 SCREWSCREW
-
233130825 SCREWSCREW
-
243131439 FUNNEL, ASSYFUNNEL, ASSY
-
253131356 O-RING, LONG AIR FUNNELO-RING, LONG AIR FUNNEL
-
263130144 JET, MAIN HEXAGON HEAD (#440)JET, MAIN HEXAGON HEAD (#440)
-
273131336 SCREW AIRSCREW AIR
-
283131371 SPRINGSPRING
-
293131372 WASHERWASHER
-
303130522 O-RINGO-RING
-
313131231 FLOAT, ASSY (1.8)FLOAT, ASSY (1.8)
-
323131248 BOLT DRAINBOLT DRAIN
-
333130863 O-RINGO-RING
-
343130824 SCREWSCREW
-
353130858 FLOAT, BODYFLOAT, BODY
-
363130861 O-RINGO-RING
-
373130860 SCREWSCREW
-
383130068 JET, PILOT (#45)JET, PILOT (#45)
-
393130769 JET, STARTER (145)JET, STARTER (145)
-
403130837 WASHERWASHER
-
413130836 SPRINGSPRING
-
423130987 ADJUSTERADJUSTER
-
433130986 CAPCAP
-
443131010 SCREW (MAG SIDE)SCREW (MAG SIDE)
-
453131009 SENSOR, ASSY (MAG SIDE)SENSOR, ASSY (MAG SIDE)
-
463130479 CAPCAP
-
473130835 PACKINGPACKING
-
487051020 VALVE, CHECK 90 DEG.VALVE, CHECK 90 DEG.
-
481253462 CARBURETOR, ASSY TM40CARBURETOR, ASSY TM40
