FRONT BRAKE для Suzuki VZ1600CA K5 - 2005 года выпуска
-
№АртикулНазвание
-
11009K1100-91754 GASKET,DISC PLATEGASKET,DISC PLATE
-
41080K4108-00072-675 DISC,FR,HOUSING GRAY+DISK GRAYDISC,FR,HOUSING GRAY+DISK GRAY
-
43048K4304-80004 PISTON-CALIPERPISTON-CALIPER
-
43049K4304-90003 PACKING,PISTONPACKING,PISTON
-
43049AK4304-91004 PACKING,SEAL,6.5X11.5X2.2PACKING,SEAL,6.5X11.5X2.2
-
43049BK4304-91107 PACKING,WIPERPACKING,WIPER
-
43057KK430-57003 CAP-BREATHERCAP-BREATHER
-
43080KK430-80001-7GN CALIPER-SUB-ASSY,FR, LEFT HAND,SILVERCALIPER-SUB-ASSY,FR, LEFT HAND,SILVER
-
43080AKK430-80001-8GN CALIPER-SUB-ASSY,FR, RIGHT HAND,SILVERCALIPER-SUB-ASSY,FR, RIGHT HAND,SILVER
-
43082K4308-20031 PAD-ASSY-BRAKEPAD-ASSY-BRAKE
-
43085KK430-85001 BREATHER-BRAKEBREATHER-BRAKE
-
92043K9204-31709 PIN,PADPIN,PAD
-
92145K9214-51568 SPRING,PADSPRING,PAD
-
92150K9215-01771 BOLT,SOCKET,8X30BOLT,SOCKET,8X30
-
92153K9215-30360 BOLT,SOCKET,8X40BOLT,SOCKET,8X40
-
92153AK9215-30577 BOLT,SOCKET,10X60BOLT,SOCKET,10X60
