TOOLKIT AND MANUAL STORAGE для Suzuki GSX-650FA L5 - 2015 года выпуска
-
№АртикулНазвание
-
147430-18H02 HOLDER, BATTERYHOLDER, BATTERY
-
294423-10G11 CUSHION, BATTERY HOLDERCUSHION, BATTERY HOLDER
-
333652-36000 CUSHIONCUSHION
-
409111-06107 BOLT (6X12)BOLT (6X12)
-
503541-0516A SCREWSCREW
-
601547-0610A BOLTBOLT
-
747410-38G01 PLATE, FUSE BOXPLATE, FUSE BOX
-
809800-21056 TOOL ASSYTOOL ASSY
-
909822-00005 CLAMP, WRENCHCLAMP, WRENCH
-
1009816-00059 HEXAGON SPANNER, 5HEXAGON SPANNER, 5
-
1109280-63003 O RING (D:3.5,ID:62.6)O RING (D:3.5,ID:62.6)
