AIR INTAKE (BLACK/RED) для Suzuki GSX-R1000 - 2017 года выпуска
-
№АртикулНазвание
-
194420-17K00 PIPE, AIR INTAKE (RH)PIPE, AIR INTAKE (RH)
-
263115-37H00 ...CUSHION, INTAKE PIPE NO.2...CUSHION, INTAKE PIPE NO.2
-
336930-60A10 ...CUSHION, INATAKE PIPE...CUSHION, INATAKE PIPE
-
494430-17K00 PIPE, AIR INTAKE (LH)PIPE, AIR INTAKE (LH)
-
563115-37H00 ...CUSHION, INTAKE PIPE NO.2...CUSHION, INTAKE PIPE NO.2
-
636930-60A10 ...CUSHION, INATAKE PIPE...CUSHION, INATAKE PIPE
-
709148-05052 NUTNUT
-
809320-08028 CUSHIONCUSHION
-
909111-06106 BOLT (6X12)BOLT (6X12)
-
1094671-17K00-YKV COVER, INTAKE (YKV - BLACK)COVER, INTAKE (YKV - BLACK)
-
11-194670-17K00-YKV COVER, INTAKE (RH) (FOR YKV - BLACK)COVER, INTAKE (RH) (FOR YKV - BLACK)
-
11-294670-17K00-YVZ COVER, INTAKE (RH) (FOR YVZ - RED)COVER, INTAKE (RH) (FOR YVZ - RED)
-
12-168275-17K00-BDK ...TAPE, INTAKE COVER (RH) (BDK - BLACK/RED/ORANGE/SILVER/BLACK FOR YKV)...TAPE, INTAKE COVER (RH) (BDK - BLACK/RED/ORANGE/SILVER/BLACK FOR YKV)
-
12-268275-17K00-BDQ ...TAPE, INTAKE COVER (RH) (BDQ - RED/BLACK/ORANGE/SILVER/BLACK FOR YVZ)...TAPE, INTAKE COVER (RH) (BDQ - RED/BLACK/ORANGE/SILVER/BLACK FOR YVZ)
-
1373415-70A00 ...CUSHION...CUSHION
-
14-194680-17K00-YKV COVER, INTAKE (LH) (FOR YKV - BLACK)COVER, INTAKE (LH) (FOR YKV - BLACK)
-
14-294680-17K00-YVZ COVER, INTAKE (LH) (FOR YVZ - RED)COVER, INTAKE (LH) (FOR YVZ - RED)
-
15-168276-17K00-BDK ...TAPE, INTAKE COVER (LH) (BDK - BLACK/RED/ORANGE/SILVER/BLACK FOR YKV)...TAPE, INTAKE COVER (LH) (BDK - BLACK/RED/ORANGE/SILVER/BLACK FOR YKV)
-
15-268276-17K00-BDQ ...TAPE, INTAKE COVER (LH) (BDQ - RED/BLACK/ORANGE/SILVER/BLACK FOR YVZ)...TAPE, INTAKE COVER (LH) (BDQ - RED/BLACK/ORANGE/SILVER/BLACK FOR YVZ)
-
1673415-70A00 ...CUSHION...CUSHION
-
1794414-17K00 COVER, INTAKE UPPER (RH)COVER, INTAKE UPPER (RH)
-
1894415-17K00 COVER, INTAKE UPPER (LH)COVER, INTAKE UPPER (LH)
-
1909132-05050 SCREW (5X12)SCREW (5X12)
-
2036930-82010 CUSHION, COVER INTAKE NO.1CUSHION, COVER INTAKE NO.1
-
2194476-38C00 CUSHION, COVER INTAKE CTR (CUT AS REQUIRED)CUSHION, COVER INTAKE CTR (CUT AS REQUIRED)
-
2294633-31J00 CUSHION, COVER SIDECUSHION, COVER SIDE
-
2309321-06013 CUSHIONCUSHION
-
2409409-06314 CLIPCLIP
-
2503541-0412B SCREWSCREW
-
2603541-0512B SCREWSCREW
