BRAKE - REAR CALIPER для Yamaha RAPTOR 90 - 2018 года выпуска
-
№АртикулНазвание
-
1BD3-F5311-00-00 HUB, REARHUB, REAR
-
2BD3-F5317-10-00 SPACER, BEARINGSPACER, BEARING
-
3BD3-F53N4-00-00 BEARINGBEARING
-
4BD3-F537Y-00-00 SEAL, DUSTSEAL, DUST
-
5BD3-F5321-00-00 PLATE, BRAKE SHOEPLATE, BRAKE SHOE
-
6BD3-F7217-10-00 BOLTBOLT
-
7BD3-F518E-10-00 SHAFTSHAFT
-
8BD3-F2143-10-00 NUTNUT
-
9BD3-F5319-00-00 SEAL, HUB DUSTSEAL, HUB DUST
-
10BD3-F5351-00-00 CAMSHAFTCAMSHAFT
-
11BD3-F5355-10-00 LEVER, CAMSHAFTLEVER, CAMSHAFT
-
12BD3-F3767-10-00 BOLTBOLT
-
13BD3-F530K-00-00 BRAKE SHOE SETBRAKE SHOE SET
-
14BD3-F6304-10-00 SPRINGSPRING
-
15BD3-F6343-10-00 NUT, ADJUSTINGNUT, ADJUSTING
-
16BD3-F6341-10-00 WIRE, BRAKE 1WIRE, BRAKE 1
-
17BD3-F7438-10-00 PIN, CLEVISPIN, CLEVIS
-
18BD3-F3458-10-00 WASHERWASHER
-
19BD3-F531E-00-00 DRUM, BRAKEDRUM, BRAKE
-
20BD3-F5336-00-00 RING 2RING 2
-
21BD3-F4477-10-00 NUTNUT
-
22BD3-F8374-10-00 BOLT, COWLINGBOLT, COWLING
-
23BD3-F5333-10-00 SPRING, RETURNSPRING, RETURN
-
24BD3-F2312-00-00 CASE, CHAIN 2CASE, CHAIN 2
-
25BD3-F7416-10-00 BOLT, FOOTRESTBOLT, FOOTREST
