09- Rear Cargo Box _42T1527 для BRP Outlander Max 400 EFI, STD, XT (International only) - 2015
-
№АртикулНазвание
-
1207065544 Hex. Screw M6 X 55. Outlander MAXHex. Screw M6 X 55. Outlander MAX
-
4293250192 Neoprene SealNeoprene Seal
-
5510004495 Belt. Outlander MAXBelt. Outlander MAX
-
6517302785 Clip. XTClip. XT
-
7529000035 Adjustement WrenchAdjustement Wrench
-
8704700148 Tool KitTool Kit
-
9705003492 Storage CoverStorage Cover
-
10708000369 Spring. Outlander MAXSpring. Outlander MAX
-
11708200066 Latch. Outlander MAXLatch. Outlander MAX
-
12708200075 SupportSupport
-
13732610072 Push Nut. Outlander MAXPush Nut. Outlander MAX
-
14708200120 Cover Latch. Outlander MAXCover Latch. Outlander MAX
-
15710002270 Remote Control. XTRemote Control. XT
-
16708200121 Cover Latch KitCover Latch Kit
-
17708200119 Box Ass'y. Outlander MAXBox Ass'y. Outlander MAX
