01- Oil Separator для BRP GTX 4-TEC, 5573/5574/5593/5594 - 2002
-
№АртикулНазвание
-
1290811840 Oil Pump HousingOil Pump Housing
-
2290837542 Pump Shaft AssyPump Shaft Assy
-
3290956675 Oil Pump Outer Rotor 16mmOil Pump Outer Rotor 16mm
-
4290811850 Oil Pump CoverOil Pump Cover
-
5290641048 Torx-Flanged Screw M6 x 16Torx-Flanged Screw M6 x 16
-
6290950970 GasketGasket
-
7290641238 Torx-Flanged Screw M6 x 25Torx-Flanged Screw M6 x 25
-
8290811891 Oil Sieve CoverOil Sieve Cover
-
9290630240 Seal RingSeal Ring
-
10290950850 GasketGasket
-
11711256570 Oil SieveOil Sieve
-
12290641228 Torx-Flanged Screw M6 x 85Torx-Flanged Screw M6 x 85
-
13290641238 Torx-Flanged Screw M6 x 25Torx-Flanged Screw M6 x 25
-
14290641238 Torx-Flanged Screw M6 x 25Torx-Flanged Screw M6 x 25
-
15290630231 GasketGasket
-
16290956761 Oil Separator HousingOil Separator Housing
-
17290256880 Oil Pressure SwitchOil Pressure Switch
-
18290811962 Oil Separator CoverOil Separator Cover
-
19290956660 Shut Off SolenoidShut Off Solenoid
-
20290630540 GasketGasket
-
21290939250 Compression SpringCompression Spring
-
22290856055 Valve DiscValve Disc
-
23290845620 Retaining RingRetaining Ring
-
24290641048 Torx-Flanged Screw M6 x 16Torx-Flanged Screw M6 x 16
-
25290630220 GasketGasket
-
26290641238 Torx-Flanged Screw M6 x 25Torx-Flanged Screw M6 x 25
-
27290956920 Plug CoverPlug Cover
-
28290660090 Rubber BracketRubber Bracket
-
29290847970 SpacerSpacer
-
30290827968 Flaat Washer 6 mmFlaat Washer 6 mm
-
31290641258 Torx-Flanged Screw M6 x 35Torx-Flanged Screw M6 x 35
-
32290851610 Front Transport BracketFront Transport Bracket
-
33290641048 Torx-Flanged Screw M6 x 16Torx-Flanged Screw M6 x 16
-
34290956970 Formed HoseFormed Hose
-
35290851673 Gear Clamp 27/8 mmGear Clamp 27/8 mm
-
290851663 Gear Clamp 22/6 mmGear Clamp 22/6 mm
-
293800060 Loctite 243, 10 mlLoctite 243, 10 ml
