09- Seat для BRP Ski-Doo Elite 1500 1st Edition - 2004
-
№АртикулНазвание
-
2510004184 Seat FrameSeat Frame
-
3510004185 Cushion Ass'yCushion Ass'y
-
4510004186 Backrest Ass'yBackrest Ass'y
-
5510004271 Cover BackrestCover Backrest
-
6210262080 Hex Forming Screw M6 X 20Hex Forming Screw M6 X 20
-
7233261414 Elastic Flanged Nut M6Elastic Flanged Nut M6
-
8510004601 LH RailLH Rail
-
9510004272 RH RailRH Rail
-
10233281414 Elastic Flanged Nut M8Elastic Flanged Nut M8
-
12510004184 Seat FrameSeat Frame
-
13510004343 Cushion Ass'yCushion Ass'y
-
14510004186 Backrest Ass'yBackrest Ass'y
-
15510004271 Cover BackrestCover Backrest
-
16224061121 Flat WasherFlat Washer
-
17210262080 Hex Forming Screw M6 X 20Hex Forming Screw M6 X 20
-
18233261414 Elastic Flanged Nut M6Elastic Flanged Nut M6
-
19510004601 LH RailLH Rail
-
20510004272 RH RailRH Rail
-
21233281414 Elastic Flanged Nut M8Elastic Flanged Nut M8
-
22510004345 Handle Ass'y. Includes 22 to 31Handle Ass'y. Includes 22 to 31
-
26515175332 Low Temperature Tubing, VinylLow Temperature Tubing, Vinyl
-
27515175494 Male Terminal Housing, 3 CircuitsMale Terminal Housing, 3 Circuits
-
28515175232 Male TerminalMale Terminal
-
29510004454 StrapStrap
-
30510004455 EyeletEyelet
-
31510004456 StopperStopper
-
32205582044 Socket Head Screw M8 X 20 Scotch GripSocket Head Screw M8 X 20 Scotch Grip
-
33234081410 Flat Washer 8 mmFlat Washer 8 mm
-
34510004240 Safety BeltSafety Belt
-
35207103044 Hex Screw M10 X 30Hex Screw M10 X 30
-
36512059057 WasherWasher
-
37233201414 Elastic Flanged Nut M10Elastic Flanged Nut M10
-
38207503046 Hex Flanged Screw M10 X 30 Scotch GripHex Flanged Screw M10 X 30 Scotch Grip
-
39234001410 Flat Washer 10 mmFlat Washer 10 mm
-
40207503544 Hex Flanged Screw M10 X 35 Scotch GripHex Flanged Screw M10 X 35 Scotch Grip
-
41224002251 Flat WasherFlat Washer
-
42233101414 Flanged Hex Nut M10Flanged Hex Nut M10
-
43207683044 Hex Flange Screw M8 X 30Hex Flange Screw M8 X 30
-
44517078700 WasherWasher
-
45233281414 Elastic Flanged Nut M8Elastic Flanged Nut M8
