CAMSHAFT(S) W/ TENSIONER для Kawasaki KLX150L (LATIN AMERICA) (BR250EHF) - 2018 года выпуска
-
№АртикулНазвание
-
1204612046-0084 SPROCKET, 36TSPROCKET, 36T
-
1204812048-0099 TENSIONER-ASSYTENSIONER-ASSY
-
1205312053-0198 GUIDE-CHAIN, REARGUIDE-CHAIN, REAR
-
12053A12053-0215 GUIDE-CHAIN, FRONTGUIDE-CHAIN, FRONT
-
1401414014-1154 PLATE-POSITIONPLATE-POSITION
-
411411AA0600 WASHER-PLAIN, 6MMWASHER-PLAIN, 6MM
-
4911849118-0897 CAMSHAFT-COMPCAMSHAFT-COMP
-
9205592055-0060 RING-O, 9.8X2.4RING-O, 9.8X2.4
-
92055A92055-0193 RING-O, 23.2X2.4RING-O, 23.2X2.4
-
9205792057-0702 CHAIN, CAMCHAIN, CAM
-
9212292122-0011 ROLLERROLLER
-
9215492154-1144 BOLT, FLANGED, 6X25BOLT, FLANGED, 6X25
-
92154A92154-1162 BOLT, FLANGED, 8X23BOLT, FLANGED, 8X23
-
92154B92154-1163 BOLT, SOCKETBOLT, SOCKET
-
92154C92154-1229 BOLT, FLANGED, 6X6BOLT, FLANGED, 6X6
-
9217292172-0832 SCREW, 6X14SCREW, 6X14
