SHOCK ABSORBER DISASSEMBLED для Ktm 1290 SUPER ADVENTURE R - 2017 года выпуска
-
№АртикулНазвание
-
1R12012 REP. KIT BEAR./SEAL UP.REP. KIT BEAR./SEAL UP.
-
246181307E BUCHSE Ш14 & LIPPENDICHTUNGBUCHSE Ш14 & LIPPENDICHTUNG
-
350180095 BLEED PLUG R 1/8BLEED PLUG R 1/8
-
450180213S27 DCC COMPR .DAMP.CONTRO L CPL. 17DCC COMPR .DAMP.CONTRO L CPL. 17
-
546811208 RUBBER CAP "DO NOT OPEN"RUBBER CAP "DO NOT OPEN"
-
636120151 SCREW PLUG M5X6SCREW PLUG M5X6
-
746811208 RUBBER CAP "DO NOT OPEN"RUBBER CAP "DO NOT OPEN"
-
815000M01S1 POWER ADJUSTER CPL. WITH SCREWPOWER ADJUSTER CPL. WITH SCREW
-
9R15015 REP AIR KIT GASKET BOTTOMREP AIR KIT GASKET BOTTOM
-
1091010358 SPRING D59 L205 180 N/MM WHITESPRING D59 L205 180 N/MM WHITE
-
1091010369 FEDER L205MM 170N/MM INNEN Ш59MMFEDER L205MM 170N/MM INNEN Ш59MM
-
1091010370 FEDER L205MM 190N/MM INNER Ш59MMFEDER L205MM 190N/MM INNER Ш59MM
-
1146180522S1 TAP ADJ. REBOUNDTAP ADJ. REBOUND
-
1250181080 BUMPERBUMPER
-
1652000149 STICKER WP WARNING INDIEN BIKE 60 X 35MMSTICKER WP WARNING INDIEN BIKE 60 X 35MM
-
9850180751S1 SHOCK ABSORBER FLUID 5 LTSHOCK ABSORBER FLUID 5 LT
-
99RP10013 REPAIR KITREPAIR KIT
