EXHAUST SYSTEM для Yamaha SRX 120 R - 2019 года выпуска
-
№АртикулНазвание
-
18MV-F1914-30-00 PANEL, SUB FRAME 3PANEL, SUB FRAME 3
-
28LN-RA525-00-00 RIVET, 16RIVET, 16
-
38MY-H5133-00-00 ...TAPE, REFLECTOR (IN 1)...TAPE, REFLECTOR (IN 1)
-
48JM-E4750-00-00 SILENCER ASSYSILENCER ASSY
-
58JP-RA514-00-00 RIVET, 5RIVET, 5
-
68JM-RAD04-00-00 SPRING, TENSION 3SPRING, TENSION 3
-
78JM-E4718-00-00 PROTECTOR, MUFFLER 1PROTECTOR, MUFFLER 1
-
88JM-F194J-00-00 STAY, MUFFLERSTAY, MUFFLER
-
98JP-RA533-00-00 RIVET, 21RIVET, 21
-
108MV-K8181-00-00 PLATE 1PLATE 1
-
118KC-RA290-00-00 SCREWSCREW
-
128JM-RA503-00-00 RIVET, BLIND 4RIVET, BLIND 4
-
138JM-F198G-00-00 COVER 2 (RIGHT HAND)COVER 2 (RIGHT HAND)
-
148JM-F198F-00-00 COVER 1 (LEFT HAND)COVER 1 (LEFT HAND)
-
158MV-F199H-00-00 ...SHIELD, HEAT (IN 1)...SHIELD, HEAT (IN 1)
-
168JP-RA352-00-00 NUT, SPRINGNUT, SPRING
