SHIFT SHAFT для Yamaha YXZ1000R EPS SS - 2017 года выпуска
-
№АртикулНазвание
-
11D7-18127-00-00 STOPPER, SCREWSTOPPER, SCREW
-
22HC-18101-00-00 SHIFT SHAFT ASSYSHIFT SHAFT ASSY
-
390508-32021-00 ...SPRING, TORSION...SPRING, TORSION
-
499002-10600-00 ...CIRCLIP...CIRCLIP
-
590201-127E1-00 ...WASHER, PLATE...WASHER, PLATE
-
690201-127E1-00 WASHER, PLATEWASHER, PLATE
-
793102-12224-00 OIL SEALOIL SEAL
-
890201-12575-00 WASHER, PLATEWASHER, PLATE
-
999002-10600-00 CIRCLIPCIRCLIP
-
10B57-82450-00-00 SHIFT ACTUATOR ASSYSHIFT ACTUATOR ASSY
-
1192012-08025-00 BOLT, BUTTON HEADBOLT, BUTTON HEAD
-
12B57-18112-00-00 ARM, SHIFTARM, SHIFT
-
1395022-06020-00 BOLT, FLANGEBOLT, FLANGE
-
14B57-18115-00-00 ROD, SHIFTROD, SHIFT
-
1595304-06700-00 NUTNUT
-
165LV-18116-00-00 JOINT, ROD 1JOINT, ROD 1
-
174XV-18154-00-00 COVER, DUSTCOVER, DUST
-
1890170-06228-00 NUT (COUNTER CLOCKWISE)NUT (COUNTER CLOCKWISE)
-
195LV-18117-00-00 JOINT, ROD 2JOINT, ROD 2
-
2090387-06372-00 COLLARCOLLAR
-
2190111-06098-00 BOLT,HEX. SOCKET BUTTONBOLT,HEX. SOCKET BUTTON
-
22B57-18300-00-00 SHIFTER ASSYSHIFTER ASSY
-
2390105-08182-00 BOLT, FLANGEBOLT, FLANGE
-
2492902-08200-00 WASHERWASHER
-
2590445-11003-00 HOSE (L280)HOSE (L280)
-
2690467-110A3-00 CLIPCLIP
