CRANKSHAFT ASSEMBLY для Arctic Cat 400 MAN (GREEN) [A2008ICH4AUSG] - 2008 года выпуска
-
№АртикулНазвание
-
13402-992 CRANKSHAFT ASSEMBLY (INC. 2-8)CRANKSHAFT ASSEMBLY (INC. 2-8)
-
23402-597 ...ROD, CONNECTING...ROD, CONNECTING
-
33402-769 ...PIN, CRANK...PIN, CRANK
-
43402-571 ...BEARING...BEARING
-
53423-440 ...WASHER...WASHER
-
63402-993 ...CRANKSHAFT - RIGHT...CRANKSHAFT - RIGHT
-
73403-019 ...CRANKSHAFT - LEFT...CRANKSHAFT - LEFT
-
83402-698 ...GEAR, CRANK BALANCER DRIVE...GEAR, CRANK BALANCER DRIVE
-
93402-055 BEARING - MIDDLEBEARING - MIDDLE
-
103423-768 SPACERSPACER
-
113402-771 CIRCLIPCIRCLIP
-
123402-216 BEARING - RIGHTBEARING - RIGHT
-
133402-594 PISTONPISTON
-
143402-595 RING, PISTON - SETRING, PISTON - SET
-
153436-015 PISTON SET (OVERSIZED 0.50 MM) (OPTIONAL)PISTON SET (OVERSIZED 0.50 MM) (OPTIONAL)
-
163003-439 CIRCLIPCIRCLIP
-
173402-596 PIN, PISTONPIN, PISTON
-
183402-051 BEARINGBEARING
-
193423-063 O-RINGO-RING
-
203423-542 SPACERSPACER
-
213402-070 SEAL, OILSEAL, OIL
-
223423-053 O-RINGO-RING
-
233402-188 RETAINER, CRANKSHAFT OIL SEAL - LEFTRETAINER, CRANKSHAFT OIL SEAL - LEFT
-
243423-018 SCREW, RETAINERSCREW, RETAINER
