REAR SUSPENSION REAR ARM ASSY. для Arctic Cat Sabercat 700 EFI LX (BLACK) - 2006 года выпуска
-
№АртикулНазвание
-
11704-455 ARM, IDLER (INC. 2-4 AND TWO NO. 5)ARM, IDLER (INC. 2-4 AND TWO NO. 5)
-
23604-095 BEARINGBEARING
-
33604-096 AXLE, INNER CARRIAGEAXLE, INNER CARRIAGE
-
41604-100 BUSHING, FLAREDBUSHING, FLARED
-
51623-010 FITTING, GREASEFITTING, GREASE
-
61704-019 ARM, REAR (INC. ONE NO. 5 AND 7)ARM, REAR (INC. ONE NO. 5 AND 7)
-
71623-011 WASHER, GREASE FITTINGWASHER, GREASE FITTING
-
88047-486 NUT, LOCKNUT, LOCK
-
91623-086 SCREW, CAP (3/8-16 X 7.500)SCREW, CAP (3/8-16 X 7.500)
-
108047-490 NUT, LOCKNUT, LOCK
-
112604-664 BUSHING, REAR ARMBUSHING, REAR ARM
-
122604-663 TUBE, AXLETUBE, AXLE
-
138050-272 WASHER, FLAT (3/8 X .734 X .063)WASHER, FLAT (3/8 X .734 X .063)
-
141623-037 SCREW, CAP (3/8-16X10 GD 8)SCREW, CAP (3/8-16X10 GD 8)
-
152604-370 AXLE, STEELAXLE, STEEL
-
161604-204 BLOCK, SPRING ADJUSTER - RIGHTBLOCK, SPRING ADJUSTER - RIGHT
-
161604-205 BLOCK, SPRING ADJUSTER - LEFTBLOCK, SPRING ADJUSTER - LEFT
-
170623-138 RING, RETAININGRING, RETAINING
-
182604-992 WHEEL, IDLERWHEEL, IDLER
-
192604-993 SLEEVE, SPRINGSLEEVE, SPRING
-
200704-926 SPRING, SUSPENSION - RIGHTSPRING, SUSPENSION - RIGHT
-
200704-927 SPRING, SUSPENSION - LEFTSPRING, SUSPENSION - LEFT
-
210623-044 WASHER, FLAT (.375 X.875)WASHER, FLAT (.375 X.875)
-
228051-277 WASHER, LOCKWASHER, LOCK
-
238002-226 SCREW, CAP (3/8-16 X1.75 G5 Z)SCREW, CAP (3/8-16 X1.75 G5 Z)
-
241704-454 SHOCK ABSORBER - REAR ARMSHOCK ABSORBER - REAR ARM
-
258002-227 SCREW, CAP (3/8-16 X2.00 G5 Z)SCREW, CAP (3/8-16 X2.00 G5 Z)
-
261604-139 SLEEVE, SHOCKSLEEVE, SHOCK
-
278041-486 NUT, LOCKNUT, LOCK
-
280704-361 LINK, REAR SHOCKLINK, REAR SHOCK
-
292604-531 AXLE, LINKAXLE, LINK
-
301623-219 SCREW, CAP (3/8-16X3.570 GR)SCREW, CAP (3/8-16X3.570 GR)
-
318020-234 SCREW, CAP (3/8-16 X 4.00 Z & )SCREW, CAP (3/8-16 X 4.00 Z & )
