02- Oil System для BRP GTI LE - 2004
-
№АртикулНазвание
-
1275000238 Oil TankOil Tank
-
2413802900 Injection Oil (12 X 1 Liter)Injection Oil (12 X 1 Liter)
-
2413803000 Injection Oil (3 X 4 Liters)Injection Oil (3 X 4 Liters)
-
2413803200 Injection Oil (205 Liters)Injection Oil (205 Liters)
-
3275000188 Filler HoseFiller Hose
-
4293650035 Tridon ClampTridon Clamp
-
5275000242 Filler NeckFiller Neck
-
6293250132 GasketGasket
-
7211100013 Nut-Neck Oil FillerNut-Neck Oil Filler
-
8275000186 Oil Cap. Includes Items 8 to 10Oil Cap. Includes Items 8 to 10
-
9275000199 Oil Tank CapOil Tank Cap
-
10293250025 O-RingO-Ring
-
11390407900 Pop Rivet 1/8''Pop Rivet 1/8''
-
12234032600 Flat Washer M3Flat Washer M3
-
13278001401 Oil Level Sensor Ass'Y. Includes Items 13 to 17Oil Level Sensor Ass'Y. Includes Items 13 to 17
-
14278000218 SealSeal
-
15278000222 Male TerminalMale Terminal
-
16278000217 Male Terminal Housing (2 Circuits)Male Terminal Housing (2 Circuits)
-
17293720008 GrommetGrommet
-
18275500549 Hose 1/4''Hose 1/4''
-
19293750002 Tie-Rap 130 mmTie-Rap 130 mm
-
20275000008 Hose 12 mm (Metre)Hose 12 mm (Metre)
-
21293650084 Norma ClampNorma Clamp
-
22275500398 Check ValveCheck Valve
-
23293720008 GrommetGrommet
-
24293710051 Fitting Elbow 90°Fitting Elbow 90°
-
25275000007 Hose 8 mmHose 8 mm
-
26293750001 Tie-Rap 94 mmTie-Rap 94 mm
-
27275000051 Oil FilterOil Filter
-
28293650042 Oetiker ClampOetiker Clamp
-
29293550004 Dielectric Grease, 150 gDielectric Grease, 150 g
-
30275500015 Oil Cap ChainOil Cap Chain
-
31415080000 Tubing 16mmTubing 16mm
