CARBURETOR для Polaris SCRAMBLER 2X4 (A00BA38CA) - 2000 года выпуска
-
№АртикулНазвание
-
13130184 TOP ASSY.TOP ASSY.
-
23130496 SPRING, THROTTLESPRING, THROTTLE
-
33130027 PLATEPLATE
-
43130476 JET NEEDLEJET NEEDLE
-
53130355 WASHERWASHER
-
63130494 VALVE, THROTTLE (1.5)VALVE, THROTTLE (1.5)
-
73130199 HOLDER, GUIDEHOLDER, GUIDE
-
83130006 SPRING, PLUNGERSPRING, PLUNGER
-
93130328 PLUNGER ASSY., STARTERPLUNGER ASSY., STARTER
-
103130436 SPRING, THROTTLE ADJUSTSPRING, THROTTLE ADJUST
-
113130447 WASHERWASHER
-
123130009 SCREW, THROTTLE STOPSCREW, THROTTLE STOP
-
133130011 SCREW, AIRSCREW, AIR
-
143130012 SPRING, AIR ADJUSTSPRING, AIR ADJUST
-
153130066 JET, PILOT(#35)JET, PILOT(#35)
-
163130025 SCREW & WASHERSCREW & WASHER
-
173130432 SCREW, GUIDESCREW, GUIDE
-
183130239 O RINGO RING
-
193130126 JET, MAIN HEX.HEADJET, MAIN HEX.HEAD
-
203130443 BOWL, FLOATBOWL, FLOAT
-
213130430 FLOAT ASSY.FLOAT ASSY.
-
223130237 CAPCAP
-
233130020 PACKING, FLOAT CHAMBERPACKING, FLOAT CHAMBER
-
243130495 NEEDLE, VALVE ASSY.NEEDLE, VALVE ASSY.
-
253130018 ARM, FLOATARM, FLOAT
-
263130361 PIN, FLOATPIN, FLOAT
-
273130047 WASHERWASHER
-
283130709 CARBURETOR (INCL. 1-31)CARBURETOR (INCL. 1-31)
-
293130596 RING, MAIN JETRING, MAIN JET
-
303130429 NEEDLE JET ASSY.NEEDLE JET ASSY.
-
313130003 E-RINGE-RING
