DRIVEN CLUTCH для Arctic Cat ZR 4000 LXR (GREEN) [S2015ZRCEFUSG] - 2015 года выпуска

№

Артикул

Название
-

0726-342 CLUTCH, DRIVEN - ASSEMBLY

CLUTCH, DRIVEN - ASSEMBLY

109 820 ₽
1

0748-772 ......BRACKET, TORQUE 42°/40° (INC. 2-3)

......BRACKET, TORQUE 42°/40° (INC. 2-3)

22 460 ₽
1

0748-770 ......BRACKET, TORQUE 36° (OVER 5,000 FT ALT.) (INC. 2-3)

......BRACKET, TORQUE 36° (OVER 5,000 FT ALT.) (INC. 2-3)

29 950 ₽
2

0648-831 ...BEARING,INNER-MACH

...BEARING,INNER-MACH

4 990 ₽
3

0648-811 ...RING,SNAP-43MM

...RING,SNAP-43MM

310 ₽
4

0648-810 SEAT, SPRING-DRIVEN

SEAT, SPRING-DRIVEN

2 700 ₽
5

0648-813 SPRING, DRIVEN CLUTCH - (BLUE)

SPRING, DRIVEN CLUTCH - (BLUE)

3 110 ₽
6

0648-827 SPACER,DRIVEN

SPACER,DRIVEN

1 870 ₽
7

0648-824 ROLLER,DRIVEN-TORLON

ROLLER,DRIVEN-TORLON

4 150 ₽
8

0648-800 WASHER,TAB LOCK-10MM

WASHER,TAB LOCK-10MM

190 ₽
9

0648-799 SCREW,CAM ROLLER-M10X1.5-40 CL 8.8

SCREW,CAM ROLLER-M10X1.5-40 CL 8.8

670 ₽
10

0648-826 CAM,BACK-2 STROKE

CAM,BACK-2 STROKE

610 ₽
11

0623-684 SCREW,SELF TAP-HWH #12X1-HILO-Z & Y

SCREW,SELF TAP-HWH #12X1-HILO-Z & Y

150 ₽
12

2623-050 SCREW,MACH-TSFH-M8X1.25X25 10.9-RIE (SILVER)

SCREW,MACH-TSFH-M8X1.25X25 10.9-RIE (SILVER)

1 240 ₽
