FRONT FORK для Kawasaki KLX 400R (KLX400-B2) - 2004 года выпуска
-
№АртикулНазвание
-
1327113271-S059 PLATEPLATE
-
1328013280-S030 HOLDER, BOOTHOLDER, BOOT
-
3208532085-S015 STOPPER, NEEDLESTOPPER, NEEDLE
-
4400544005-S009 PIPE-LEFT FORK OUTERPIPE-LEFT FORK OUTER
-
4400644006-S009 PIPE-RIGHT FORK OUTERPIPE-RIGHT FORK OUTER
-
4401344013-S006 PIPE-FORK INNERPIPE-FORK INNER
-
4401844018-S004 PISTON-FORKPISTON-FORK
-
4402344023-S003 CYLINDER-SET-FORKCYLINDER-SET-FORK
-
4402644026-S009 SPRING-FRONT FORKSPRING-FRONT FORK
-
44026A44026-S011 SPRING-FRONT FORKSPRING-FRONT FORK
-
4402844028-S003 GUIDE-FORK SPRINGGUIDE-FORK SPRING
-
4402944029-S002 SEAT-FORK SPRINGSEAT-FORK SPRING
-
4406544065-S002 BUSHING-FRONT FORKBUSHING-FRONT FORK
-
44065A44065-S003 BUSHING-FRONT FORKBUSHING-FRONT FORK
-
4407144071-S009 DAMPER-ASSY, RIGHT HANDDAMPER-ASSY, RIGHT HAND
-
44071A44071-S010 DAMPER-ASSY, LEFT HANDDAMPER-ASSY, LEFT HAND
-
4610246102-S004 RODROD
-
4900649006-S032-503 BOOT, (BLACK)BOOT, (BLACK)
-
4911649116-S004 VALVE-ASSYVALVE-ASSY
-
5603056030-S012 LABELLABEL
-
9202692026-S127 SPACERSPACER
-
9203392033-S051 RING-SNAPRING-SNAP
-
9204992049-S058 SEAL-OILSEAL-OIL
-
9205592055-S075 RING-ORING-O
-
92055A92055-S076 RING-ORING-O
-
92055B92055-S077 RING-ORING-O
-
92055C92055-S078 RING-ORING-O
-
92055D92055-S079 RING-ORING-O
-
9207292072-S008 BAND, BOOTBAND, BOOT
-
92072A92072-S010 BAND, BOOTBAND, BOOT
-
9209392093-S044 SEALSEAL
-
9215392153-S350 BOLTBOLT
-
92153A92153-S351 BOLT, 8X35BOLT, 8X35
-
9217292172-S198 SCREW, PLUGSCREW, PLUG
-
9220092200-S196 WASHER, SEALWASHER, SEAL
-
92200A92200-S197 WASHERWASHER
-
9221092210-S124 NUTNUT
