GAS TANK ASSEMBLY для Arctic Cat PROWLER (GREEN) [U2008P1S4BUSG] - 2008 года выпуска
-
№АртикулНазвание
-
10570-189 TANK, GAS - ASSEMBLY (INC. 2-8)TANK, GAS - ASSEMBLY (INC. 2-8)
-
20470-575 ...CAP, GAS TANK...CAP, GAS TANK
-
30570-118 ...FUEL FILTER ASSEMBLY (INC. 4-6)...FUEL FILTER ASSEMBLY (INC. 4-6)
-
40470-521 ......SEAL, FUEL LEVEL SENSOR......SEAL, FUEL LEVEL SENSOR
-
50470-475 ......FILTER, FUEL......FILTER, FUEL
-
60423-603 ......CLAMP, HOSE......CLAMP, HOSE
-
71623-158 ...SCREW, PLASTITE-TSPNH 1/4-10X.500 Z & BLK...SCREW, PLASTITE-TSPNH 1/4-10X.500 Z & BLK
-
80470-639 ...PLATE, MOUNTING - FUEL LEVEL SENSOR...PLATE, MOUNTING - FUEL LEVEL SENSOR
-
90423-688 CLAMP, HOSECLAMP, HOSE
-
100410-070 HOSE, FUEL - 25 FTHOSE, FUEL - 25 FT
-
110410-143 HOSE, FUEL - 25 FTHOSE, FUEL - 25 FT
-
120423-689 CLAMP, HOSECLAMP, HOSE
-
130470-702 FITTING, STRAIGHTFITTING, STRAIGHT
-
140623-454 CLIP, SNAP-IN (SPEEDO-CABLE)CLIP, SNAP-IN (SPEEDO-CABLE)
-
158476-620 SCREW, MACHINESCREW, MACHINE
-
160470-758 PUMP, FUELPUMP, FUEL
-
170623-038 NUT, LOCKNUT, LOCK
-
188476-625 SCREW, MACHINESCREW, MACHINE
-
190470-544 BRACKET, GAS TANK MOUNTINGBRACKET, GAS TANK MOUNTING
-
200623-784 SCREW, SELF TAP-TSTRH #10-12X3/4 TP A BLKSCREW, SELF TAP-TSTRH #10-12X3/4 TP A BLK
-
210570-127 STRAP, GAS TANKSTRAP, GAS TANK
-
220570-128 STRAP, GAS TANKSTRAP, GAS TANK
-
238427-602 NUT, HEXNUT, HEX
-
248476-650 SCREW, MACHINESCREW, MACHINE
-
250423-357 NUT, STAMPEDNUT, STAMPED
-
261406-886 INSET, GAS TANK CAPINSET, GAS TANK CAP
-
270123-811 CABLE TIE - 4 IN.CABLE TIE - 4 IN.
