FOOTREST для Suzuki VZ1500 M90 - 2017 года выпуска
-
№АртикулНазвание
-
143510-40H00 BRACKET, FRONT FOOTREST (RH)BRACKET, FRONT FOOTREST (RH)
-
243520-40H00 BRACKET, FRONT FOOTREST (LH)BRACKET, FRONT FOOTREST (LH)
-
309103-10378 BOLT (10X25)BOLT (10X25)
-
443531-48G01 BAR, FRONT FOOTREST (RH)BAR, FRONT FOOTREST (RH)
-
543541-48G01 BAR, FRONT FOOTREST (LH)BAR, FRONT FOOTREST (LH)
-
643550-48G00 RUBBERRUBBER
-
708319-2106A NUTNUT
-
809208-08010 PIN (8X33.2)PIN (8X33.2)
-
909448-14047 SPRINGSPRING
-
1008332-1106A E RINGE RING
-
1143576-07D01 BOLT, BANK SENSORBOLT, BANK SENSOR
-
1243600-40H60 FOOTREST, PILLION (RH)FOOTREST, PILLION (RH)
-
1343610-39G10 ...BAR...BAR
-
1443612-39G00 ...RUBBER...RUBBER
-
1509208-06007 ...PIN...PIN
-
1609160-19024 ...WASHER (19.5X32X2)...WASHER (19.5X32X2)
-
1708332-1104A ...E RING...E RING
-
1843700-40H70 FOOTREST, PILLION (LH)FOOTREST, PILLION (LH)
-
1943610-39G10 ...BAR...BAR
-
2043612-39G00 ...RUBBER...RUBBER
-
2109208-06007 ...PIN...PIN
-
2209160-19024 ...WASHER (19.5X32X2)...WASHER (19.5X32X2)
-
2308332-1104A ...E RING...E RING
-
2409103-08412 BOLT (8X16)BOLT (8X16)
