CHAINCASE ASSEMBLY (REVERSE MODELS) для Polaris 500 XC SP EDGE/EDGE X F/O (S02NP5CS) - 2002 года выпуска
-
№АртикулНазвание
-
13610030 SEAL, OILSEAL, OIL
-
25132237 NUT, CHAIN ADJUSTER (3/8, 16)NUT, CHAIN ADJUSTER (3/8, 16)
-
37512470 SCREWSCREW
-
41332213 TIGHTENER, CHAINCASETIGHTENER, CHAINCASE
-
43553002 BEARINGBEARING
-
45630123 WHEEL, C/C IDLERWHEEL, C/C IDLER
-
47558702 WASHER THRUSTWASHER THRUST
-
47662210 PIN, CHAIN TIGHTENERPIN, CHAIN TIGHTENER
-
41332213 TIGHTENER, CHAINCASETIGHTENER, CHAINCASE
-
53514309 BEARING, BALLBEARING, BALL
-
67718406 RING, RETAININGRING, RETAINING
-
73221098 SPROCKET SPLINE (22 TEETH, 3/4W, HV, PM)SPROCKET SPLINE (22 TEETH, 3/4W, HV, PM)
-
87571620 WASHER, SLOTTEDWASHER, SLOTTED
-
97542811 NUTNUT
-
107661401 COTTER PINCOTTER PIN
-
115411497 GASKET, O-RING CHAINCASEGASKET, O-RING CHAINCASE
-
122200363 SHIFT FORK/SHAFT KIT [INCL. 17, 19]SHIFT FORK/SHAFT KIT [INCL. 17, 19]
-
125130805 FORK, SHIFTFORK, SHIFT
-
135133117 COVER (CC, REV, MACH, 7.92)COVER (CC, REV, MACH, 7.92)
-
141332250 DIPSTICK ASSY., (W/MAGNET EDGE)DIPSTICK ASSY., (W/MAGNET EDGE)
-
157512242 SCREWSCREW
-
163610029 SEAL, OILSEAL, OIL
-
177661826 PIN, SHIFT FORKPIN, SHIFT FORK
-
187710415 RING, RETAINERRING, RETAINER
-
191341388-067 WELD, SHIFT SHAFT (BLACK)WELD, SHIFT SHAFT (BLACK)
-
207555877 WASHER, THRUSTWASHER, THRUST
-
211341075 GEAR, SPUR PINIONGEAR, SPUR PINION
-
213554508 BEARING, NEEDLEBEARING, NEEDLE
-
223221109 CHAIN (HYVO.74P, 3/4W)CHAIN (HYVO.74P, 3/4W)
-
231341241 SPROCKET, PINIONSPROCKET, PINION
-
233554508 BEARING, NEEDLEBEARING, NEEDLE
-
247512019 SCREWSCREW
-
255131770 SHAFT, PINION W/WRENCH FLATSSHAFT, PINION W/WRENCH FLATS
-
265243162 BRACKET, CHAIN RETENTION (7.05)BRACKET, CHAIN RETENTION (7.05)
-
277515477 BOLTBOLT
-
281332220 JACKSHAFT ASSY. (SEE DRIVE TRAIN REF. 18)JACKSHAFT ASSY. (SEE DRIVE TRAIN REF. 18)
-
295132773 CHAINCASE (7.92 CD, ALUM)CHAINCASE (7.92 CD, ALUM)
-
307052115 PLUGPLUG
-
317555871 WASHER, REVERSEWASHER, REVERSE
-
321341227 SPROCKET ASSY. (40 TEETH, REV, 3/4W, PM)SPROCKET ASSY. (40 TEETH, REV, 3/4W, PM)
-
335130720 COUPLER, DRIVECOUPLER, DRIVE
-
341341410 REVERSE GEAR ASSY.REVERSE GEAR ASSY.
-
357041887 SPRING, COMPRESSIONSPRING, COMPRESSION
-
365130727 RETAINER, DRIVE COUPLERRETAINER, DRIVE COUPLER
-
377552901 LOCK WASHERLOCK WASHER
-
387517581 SCREWSCREW
