BRAKE - FRONT CALIPER ASSY. для Suzuki RM65K3 - 2003 года выпуска
-
№АртикулНазвание
-
14079K1407-91130 HOLDER-ASSY.,CALIPER (FRONT)HOLDER-ASSY.,CALIPER (FRONT)
-
41080K4108-01470 DISCDISC
-
43048K4304-81089 PISTON-CALIPERPISTON-CALIPER
-
43056K4305-61056 BREATHER-BRAKEBREATHER-BRAKE
-
43057K4305-71001 CAP-BREATHERCAP-BREATHER
-
43080K4308-05131 CALIPER-SUB-ASSY. (FRONT)CALIPER-SUB-ASSY. (FRONT)
-
43082K4308-21242 PAD-ASSY.-BRAKEPAD-ASSY.-BRAKE
-
49006K4900-61088 BOOT, CALIPERBOOT, CALIPER
-
49006K4900-61242 BOOT, CALIPERBOOT, CALIPER
-
92049K9204-91331 SEAL-OIL, PISTONSEAL-OIL, PISTON
-
92093K9209-31272 SEAL, PISTONSEAL, PISTON
-
92145K9214-51269 SPRING, PADSPRING, PAD
-
92150K9215-01144 BOLTBOLT
-
92151K9215-11799 BOLT, DISC PLATE, (6MM)BOLT, DISC PLATE, (6MM)
-
130KK130-P0840 BOLT-FLANGEDBOLT-FLANGED
