SUSPENSION - REAR ARM для Suzuki RM65K3 - 2003 года выпуска
-
№АртикулНазвание
-
11012K1101-21263 CAPCAP
-
12053K1205-31436 GUIDE-CHAIN, (REAR)GUIDE-CHAIN, (REAR)
-
12053K1205-31456 GUIDE-CHAIN (FRONT)GUIDE-CHAIN (FRONT)
-
13070K1307-01347 GUIDE, CHAINGUIDE, CHAIN
-
33001KK330-01163-4CE ARM-COMP-SWING, (SILVER)ARM-COMP-SWING, (SILVER)
-
33032K3303-21194 SHAFT-SWING ARMSHAFT-SWING ARM
-
33040K3304-01188 ADJUSTER-CHAINADJUSTER-CHAIN
-
42036K4203-61067 SLEEVE, SWING ARM (L=34)SLEEVE, SWING ARM (L=34)
-
92001K9200-11463 BOLT (6X39)BOLT (6X39)
-
92015K9201-51433 NUT, FLANGED (12MM)NUT, FLANGED (12MM)
-
92046K9204-61046 BEARING-NEEDLEBEARING-NEEDLE
-
92143K9214-31676 COLLARCOLLAR
-
92152K9215-21215 COLLARCOLLAR
-
130KK130-G0650 BOLT-FLANGED (6X50)BOLT-FLANGED (6X50)
-
220KK220-B0508 SCREW-PAN-CROS (5X8)SCREW-PAN-CROS (5X8)
-
311KK311-B0600 NUT-HEX, (6MM)NUT-HEX, (6MM)
