GEAR CHANGE DRUM W/ SHIFT FORK для Suzuki RM65K3 - 2003 года выпуска
-
№АртикулНазвание
-
13140K1314-01300 FORK-SHIFT (INPUT)FORK-SHIFT (INPUT)
-
13140K1314-01301 FORK-SHIFT, OUTPUTFORK-SHIFT, OUTPUT
-
13141K1314-11220 DRUM-CHANGEDRUM-CHANGE
-
13271K1327-11417 PLATEPLATE
-
13280K1328-01179 HOLDERHOLDER
-
49047K4904-71009 ROD-SHIFT, 10X90ROD-SHIFT, 10X90
-
92009K9200-91862 SCREW, 6X14SCREW, 6X14
-
92042KK920-42014 PIN, DOWEL, 4X15.8PIN, DOWEL, 4X15.8
-
92150K9215-01604 BOLT, SOCKET, 8X30BOLT, SOCKET, 8X30
-
610KK610-A0408 ROLLER, 4X8ROLLER, 4X8
