BRAKE - REAR CALIPER для Yamaha BLASTER YFS200M (5KJ1) - 2000 года выпуска
-
№АртикулНазвание
-
12XJ-25712-00-00 BRACKET, DISCBRACKET, DISC
-
22XJ-25831-50-00 DISC, BRAKEDISC, BRAKE
-
390109-081F0-00 BOLTBOLT
-
42XJ-25715-00-00 COVER 1COVER 1
-
52XJ-25367-00-00 COVER, HUB DUSTCOVER, HUB DUST
-
693440-44158-00 CIRCLIPCIRCLIP
-
793440-36159-00 CIRCLIPCIRCLIP
-
82XJ-25810-50-00 CALIPER ASSYCALIPER ASSY
-
92XJ-25916-00-00 ...PLUG...PLUG
-
102XJ-25726-01-00 ...BRAKE LEVER SET...BRAKE LEVER SET
-
112XJ-25771-00-00 ...RATCHET, ADJUSTING...RATCHET, ADJUSTING
-
122XJ-25772-00-00 ...SPRING, RATCHET FIX...SPRING, RATCHET FIX
-
132XJ-25818-00-00 ...BOLT, CALIPER...BOLT, CALIPER
-
142XJ-25811-00-00 ...PAD, CALIPER 2...PAD, CALIPER 2
-
152XJ-25734-00-00 ...PIN 1...PIN 1
-
162XJ-25689-00-00 ...PLATE, GUIDE...PLATE, GUIDE
-
172XJ-26351-01-00 CABLE, BRAKECABLE, BRAKE
-
1890201-08609-00 WASHER, PLATEWASHER, PLATE
-
1990105-08520-00 BOLT, WASHER BASEDBOLT, WASHER BASED
-
2090105-08521-00 BOLT, WASHER BASEDBOLT, WASHER BASED
-
212XJ-25721-00-00 BRACKET, CALIPERBRACKET, CALIPER
