FUEL TANK для Yamaha XT 250 - 2018 года выпуска
-
№АртикулНазвание
-
13C5-24110-40-P0 FUEL TANK COMP. (MBL2 - MAT BLACK) (CALIF ONLY)FUEL TANK COMP. (MBL2 - MAT BLACK) (CALIF ONLY)
-
13C5-24110-20-P0 FUEL TANK COMP. (MBL2 - MAT BLACK) (EXCEPT CALIF)FUEL TANK COMP. (MBL2 - MAT BLACK) (EXCEPT CALIF)
-
25XT-13907-11-00 FUEL PUMP COMP.FUEL PUMP COMP.
-
33D7-24491-00-00 BRACKET, FUEL PUMPBRACKET, FUEL PUMP
-
41S4-24486-00-00 O-RINGO-RING
-
592012-05016-00 BOLT, BUTTON HEADBOLT, BUTTON HEAD
-
65VK-24602-30-00 CAP ASSY (CALIF ONLY)CAP ASSY (CALIF ONLY)
-
65VK-24602-20-00 CAP ASSY (EXCEPT CALIF)CAP ASSY (EXCEPT CALIF)
-
73C5-24181-10-00 DAMPER, LOCATING 1DAMPER, LOCATING 1
-
83C5-24183-00-00 DAMPER, LOCATING 3DAMPER, LOCATING 3
-
93C5-24182-10-00 DAMPER, LOCATING 2DAMPER, LOCATING 2
-
103C5-24185-10-00 DAMPER, LOCATING 5DAMPER, LOCATING 5
-
113C5-24184-10-00 DAMPER, LOCATING 4DAMPER, LOCATING 4
-
121UA-82591-00-00 BANDBAND
-
133C5-24188-00-00 MOLD, FUEL TANKMOLD, FUEL TANK
-
143C5-24186-00-00 WASHER, SPECIALWASHER, SPECIAL
-
1590202-10165-00 WASHER, PLATEWASHER, PLATE
-
1690109-06265-00 BOLTBOLT
-
1790202-10003-00 WASHER, PLATEWASHER, PLATE
-
1890201-06074-00 WASHER, PLATEWASHER, PLATE
-
1990149-06298-00 SCREWSCREW
-
203C5-Y217W-8A-00 SCOOP COMP, AIR 1SCOOP COMP, AIR 1
-
213C5-2137C-R0-00 ...GRAPHIC, SCOOP AIR SET 1...GRAPHIC, SCOOP AIR SET 1
-
223C5-24125-00-00 ...SEAL, AIR SHROUD 1...SEAL, AIR SHROUD 1
-
233C5-24126-00-00 ...SEAL, AIR SHROUD 2...SEAL, AIR SHROUD 2
-
243C5-2414H-00-00 ...DAMPER, PLATE 1...DAMPER, PLATE 1
-
253C5-2414J-00-00 ...DAMPER, PLATE 2...DAMPER, PLATE 2
-
263C5-2414K-00-00 ...DAMPER, PLATE 3...DAMPER, PLATE 3
-
273C5-2414N-00-00 ...DAMPER, PLATE 4...DAMPER, PLATE 4
-
2890480-01559-00 ...GROMMET...GROMMET
-
291YB-24161-40-00 ...EMBLEM 1...EMBLEM 1
-
303C5-Y217X-8A-00 SCOOP COMP., AIR 2SCOOP COMP., AIR 2
-
313C5-2137D-R0-00 ...GRAPHIC, SCOOP AIR SET 2...GRAPHIC, SCOOP AIR SET 2
-
323C5-2414H-00-00 ...DAMPER, PLATE 1...DAMPER, PLATE 1
-
333C5-2414J-00-00 ...DAMPER, PLATE 2...DAMPER, PLATE 2
-
3490480-01559-00 ...GROMMET...GROMMET
-
351YB-24161-40-00 ...EMBLEM 1...EMBLEM 1
-
3690111-05045-00 BOLT, HEX. SOCKET BUTTONBOLT, HEX. SOCKET BUTTON
-
373C5-2414P-00-00 DAMPER, PLATE 5DAMPER, PLATE 5
-
383C5-2416F-00-00 INSULATOR, FUEL TANK 1INSULATOR, FUEL TANK 1
-
391TP-2118K-A1-00 LABEL, CAUTIONLABEL, CAUTION
-
403C5-24170-00-00 CANISTER ASSY (CALIF ONLY)CANISTER ASSY (CALIF ONLY)
-
413C5-2419E-00-00 COVER, CANISTER (CALIF ONLY)COVER, CANISTER (CALIF ONLY)
-
4290480-15342-00 GROMMET (CALIF ONLY)GROMMET (CALIF ONLY)
-
4390387-063G3-00 COLLAR (CALIF ONLY)COLLAR (CALIF ONLY)
-
4497007-06025-00 BOLT (CALIF ONLY)BOLT (CALIF ONLY)
-
4592907-06600-00 WASHER, PLATE (CALIF ONLY)WASHER, PLATE (CALIF ONLY)
-
465RB-24180-00-00 ROLL OVER VALVE ASSY (CALIF ONLY)ROLL OVER VALVE ASSY (CALIF ONLY)
-
4790464-15014-00 CLAMP (CALIF ONLY)CLAMP (CALIF ONLY)
-
481YB-24321-00-00 PIPE 10 (CALIF ONLY)PIPE 10 (CALIF ONLY)
-
491YB-24322-00-00 PIPE 11 (CALIF ONLY)PIPE 11 (CALIF ONLY)
-
503C5-24324-00-00 PIPE 13 (CALIF ONLY)PIPE 13 (CALIF ONLY)
-
5190467-090A2-00 CLIP (CALIF ONLY)CLIP (CALIF ONLY)
-
5290467-11106-00 CLIP (CALIF ONLY)CLIP (CALIF ONLY)
-
5395602-05200-00 NUT, SELF-LOCKING (CALIF ONLY)NUT, SELF-LOCKING (CALIF ONLY)
