TIE ROD ASSEMBLY для Arctic Cat AC 440 SNO PRO GREEN INTERNATIONAL - 2005 года выпуска
-
№АртикулНазвание
-
11705-086 SHAFT, STEERING (INC. 2)SHAFT, STEERING (INC. 2)
-
20605-807 BEARINGBEARING
-
31623-400 SCREW, CAPSCREW, CAP
-
41705-083 LINK, STEERING, BOTTOM (INC. ONE NO. 5 AND TWO NO. 6)LINK, STEERING, BOTTOM (INC. ONE NO. 5 AND TWO NO. 6)
-
50605-808 INSERT, STEERINGINSERT, STEERING
-
60605-803 INSERT, STEERINGINSERT, STEERING
-
71705-082 LINK, STEERING, TOP (INC. ONE NO. 5 AND TWO NO. 6)LINK, STEERING, TOP (INC. ONE NO. 5 AND TWO NO. 6)
-
88047-486 NUT, LOCKNUT, LOCK
-
91623-365 SCREW, MACHINESCREW, MACHINE
-
100605-804 SPACERSPACER
-
118047-366 NUT, LOCKNUT, LOCK
-
120606-654 PLUGPLUG
-
130623-954 WASHER, THRUSTWASHER, THRUST
-
140605-806 SPACERSPACER
-
150623-955 WASHER, THRUSTWASHER, THRUST
-
168020-226 SCREW, CAPSCREW, CAP
-
170605-788 ROD, END (RIGHT)ROD, END (RIGHT)
-
188047-486 NUT, LOCKNUT, LOCK
-
190123-917 NUT, HEX (LEFT)NUT, HEX (LEFT)
-
200605-798 TUBE, TIE ROD, SPINDLETUBE, TIE ROD, SPINDLE
-
210623-294 NUT, HEX (RIGHT)NUT, HEX (RIGHT)
-
220605-607 BALL JOINT (LEFT)BALL JOINT (LEFT)
-
231623-394 SCREW, CAPSCREW, CAP
-
240605-785 ARM, SHAFTARM, SHAFT
-
250623-956 SNAP RINGSNAP RING
-
268005-584 SCREW, CAPSCREW, CAP
Все узлы модели:
- A-ARM ASSEMBLY
- AIR SILENCER ASSEMBLY
- BELLY PAN ASSEMBLY
- BELT GUARD ASSEMBLY
- CARBURETOR
- COMPLETE CHASSIS
- CONSOLE AND SWITCH ASSEMBLY
- CONTROL ASSEMBLY
- COOLING ASSEMBLY
- CRANKCASE ASSEMBLY
- CYLINDER AND HEAD ASSEMBLY
- DRIVE CLUTCH
- DRIVE TRAIN SHAFTS AND BRAKE ASSEMBLIES
- DRIVE/DROPCASE ASSEMBLY
- DRIVEN CLUTCH
- ELECTRICAL
- ENGINE AND RELATED PARTS
- EXHAUST ASSEMBLY
- FOOTREST AND STEERING SUPPORT ASSEMBLY
- FRONT FRAME ASSEMBLY
- FRONT SUSPENSION SHOCK ABSORBER
- GAS TANK ASSEMBLY
- HANDLEBAR ASSEMBLY
- HEADLIGHT- INSTRUMENTS- AND WIRING ASSEMBLIES
- HOOD AND WINDSHIELD ASSEMBLY
- HYDRAULIC BRAKE CONTROL ASSEMBLY
- IDLER WHEEL ASSEMBLY
- MAGNETO
- PISTON AND CRANKSHAFT
- REAR SUSPENSION FRONT ARM ASSEMBLY
- REAR SUSPENSION FRONT ARM SHOCK ABSORBER
- REAR SUSPENSION REAR ARM ASSEMBLY
- REAR SUSPENSION REAR ARM SHOCK ABSORBER
- REAR SUSPENSION SHOCK ABSORBER ASSEMBLY
- RECOIL STARTER
- REED VALVE ASSEMBLY
- RELATED ITEMS
- SEAT ASSEMBLY
- SERVOMOTOR ASSEMBLY
- SHOCK ABSORBER AND SWAY BAR ASSEMBLY
- SKI AND SPINDLE ASSEMBLY
- SLIDE RAIL AND TRACK ASSEMBLY
- STEERING POST ASSEMBLY
- • TIE ROD ASSEMBLY
- TUNNEL- REAR BUMPER- AND TAILLIGHT ASSEMBLIES
- WATER PUMP/WATER MANIFOLD ASSEMBLY
