A-ARM AND SWAY BAR ASSEMBLY для Arctic Cat XF 8000 HIGH COUNTRY LTD ES 153 GREEN INTERNATIONAL - 2018 года выпуска
-
№АртикулНазвание
-
13703-416 A-ARM, UPPER - BLACK (INC. 2-3)A-ARM, UPPER - BLACK (INC. 2-3)
-
28420-202 ...NUT...NUT
-
31605-151 ...BEARING, END...BEARING, END
-
42623-067 SCREW, SHOULDERSCREW, SHOULDER
-
52623-066 TRI NUTTRI NUT
-
68413-645 SCREW, CAPSCREW, CAP
-
73603-258 AXLEAXLE
-
88437-604 NUT, LOCKNUT, LOCK
-
92603-946 BUSHINGBUSHING
-
102703-793 BAR, SWAYBAR, SWAY
-
112603-947 BUSHINGBUSHING
-
122603-857 BRACKET, MOUNTING - SWAY BARBRACKET, MOUNTING - SWAY BAR
-
138468-621 SCREW, MACHINESCREW, MACHINE
-
142623-190 SCREW, CAPSCREW, CAP
-
158427-802 NUTNUT
-
163603-295 LINK, SWAY BARLINK, SWAY BAR
-
173703-368 A-ARM, LOWER - RIGHT - BLACK (INC. TWO NO. 18-19)A-ARM, LOWER - RIGHT - BLACK (INC. TWO NO. 18-19)
-
173703-369 A-ARM, LOWER - LEFT - BLACK (INC. TWO NO. 18-19)A-ARM, LOWER - LEFT - BLACK (INC. TWO NO. 18-19)
-
181603-895 ...BEARING...BEARING
-
192603-911 ...BEARING...BEARING
-
201623-965 NUT, LOCKNUT, LOCK
-
212603-909 BRACE, LOWER A-ARM - FRONTBRACE, LOWER A-ARM - FRONT
-
222603-916 AXLE, INNER - LOWER A-ARM - FRONTAXLE, INNER - LOWER A-ARM - FRONT
-
231623-953 SCREW, CAPSCREW, CAP
-
248415-075 SCREW, CAPSCREW, CAP
-
252603-543 AXLE, LOWER A-ARM - REARAXLE, LOWER A-ARM - REAR
-
268427-002 NUT, LOCKNUT, LOCK
-
278427-202 NUT, LOCKNUT, LOCK
