GEAR CHANGE DRUM W/ SHIFT FORK для Suzuki RM100K3 - 2003 года выпуска
-
№АртикулНазвание
-
13091K1309-11390 HOLDER, CHANGE DRUMHOLDER, CHANGE DRUM
-
13140K1314-01302 FORK, SHIFT, 5TH & 6THFORK, SHIFT, 5TH & 6TH
-
13140K1314-01303 FORK, SHIFT, 2ND & 3RDFORK, SHIFT, 2ND & 3RD
-
13140K1314-01304 FORK, SHIFT, LOW & 4THFORK, SHIFT, LOW & 4TH
-
13141K1314-11120 DRUM, CHANGEDRUM, CHANGE
-
49047K4904-71063 ROD, SHIFT (5.9X10X64.5)ROD, SHIFT (5.9X10X64.5)
-
49047K4904-71064 ROD, SHIFT (5.9X10X81)ROD, SHIFT (5.9X10X81)
-
92045K9204-51058 BEARING, BALL (6905Z)BEARING, BALL (6905Z)
-
115KK115-G0825 BOLT, UPSET (SMALL)BOLT, UPSET (SMALL)
-
610KK610-A0408 ROLLER (4X8)ROLLER (4X8)
