GENERATOR для Suzuki RM-Z250K6 - 2006 года выпуска
-
№АртикулНазвание
-
21003K2100-30027 STATORSTATOR
-
21007K2100-70070 ROTOR, I=4.1ROTOR, I=4.1
-
21007AK2100-70071 ROTOR, I=3.6ROTOR, I=3.6
-
21007BK2100-70072 ROTOR, I=4.8ROTOR, I=4.8
-
92015K9201-51428 NUT, FLANGED,10MMNUT, FLANGED,10MM
-
120KK120-P0525 BOLT-SOCKET, 5X25BOLT-SOCKET, 5X25
-
130KK130-P0510 BOLT-FLANGED, 5X10BOLT-FLANGED, 5X10
-
510KK510-A3200 KEY-WOODRUFFKEY-WOODRUFF
